Bose 2150 User Manual

31
AC Input/Output PCB Assembly
Resistors
ELECTRICAL PART LIST
Capacitors
Transistors
Integrated Circuits
Miscellaneous
Reference
Designator
Description Vendor Part
Number
Bose
®
®®
®
Part
Number
Note
R101 1k, CF, 1/8W, 5% 1124.0102 4
R102 18 Ohm, HM, CC, 1/2W, 5% 1354.0180 187934-
18R0
3
R103 8.2 Ohm, CF, 1/2W, 5% 1324.0829 182857 3
Reference
Designator
Description Vendor Part
Number
Bose Part
Number
Note
C100 .10uF, MP, 250VAC, UL/CSA 2462.1104 182846 3
C101 .10uF, MP, 250VAC, UL/CSA 2462.1104 182846 3
Reference
Designator
Description Vendor Part
Number
Bose Part
Number
Note
Q100 Triac, BTA41-700B, 40 Amp, 700V 3280.0005 262161 3
Reference
Designator
Description Vendor Part
Number
Bose Part
Number
Note
U100 OPTO, LED/MOSFET, PS7341-1A 3610.0008 262162 3
Reference
Designator
Description Vendor Part
Number
Bose Part
Number
Note
J100 Conn, Hdr, .1 CTR, 2 Pin 4205.0001 262163
J101 Conn, Hdr, HZ, FEM, .2 in, 8 Pos.
(Channel 2 speaker output)
4227.0027 262164 3
J102 Conn, Hdr, HZ, FEM, .2 in, 8 Pos.
(Channel 1 speaker output)
4227.0027 262164 3
F100 8A, 250V, MDA 315-13003-00 262165 3
- Fuse Holder, Clip, .25 Dia, PC MNT
Clips for F100
4610.0008 262166 Qty. 2,
3
- Heatsink, .75H, TO-3, Custom Hole
Heatsink for Q100
5630.0009 199778 Qty. 1
- Screw, MA, PHP, 6-32x3/8, BLK
Attach heatsink to Q100
151-20052-00 262167 Qty. 1
- Standoff, .25OD, 6-32x.187, SWG,
BRS (Used on Q100)
118-80031-02 199749 Qty. 1
