ELECTRICAL PART LIST

Miscellaneous

Amplifier PCB Assembly (board part number 8005.0587)

Reference

Designator

Description Bose

Part

Number

Vendor Part

Number

Note

H1 GROMMET, 1/4 ID x 9/16 OD - 5820.0007 4

H2 GROMMET, 1/4 ID x 9/16 OD - 5820.0007 4

H3 GROMMET, 1/4 ID x 9/16 OD - 5820.0007 4

H4 GROMMET, 1/4 ID x 9/16 OD - 5820.0007 4

J601 CABLE, IDC, PCB/PLG 10, CON, 4 IN

262139 4148.0018

J602 CABLE, IDC, PCB/PLG 10, CON, 4 IN

262139 4148.0018

P600 CONN, PLUG, HSG, 2.13mm, 4 PIN 262140 4206.0004

RT600 THERMISTOR, PTC, 2.2k at 60 DEG

262126 L.1200.0001

WL610 CONN, TAB, 0.25", RTANG, PC MNT 262141 L.4200.0019

WL611 CONN, TAB, 0.25", RTANG, PC MNT 262141 L.4200.0019

WL620 CONN, TAB, 0.25", RTANG, PC MNT 262141 L.4200.0019

WL621 CONN, TAB, 0.25", RTANG, PC MNT 262141 L.4200.0019

- CONN, HDR, 0.1" CTR, FEM, 8-SIP

(sockets for U605)

- L.4205.0070 Qty. 2

- CONN, HDR, 0.1" CTR, FEM, 11-SIP

(sockets for U605)

- L.4205.0071 Qty. 2

- CONN, TERM, 2.13mm, 14-20 AWG,

FEM (terminals for P600)

- L.4211.0002 Qty. 4
