Power Supply PCB Assembly
Diodes
ELECTRICAL PART LIST
Integrated Circuits
Reference
Designator
Description Vendor Part
Number
Bose
®
®®
®
Part
Number
Note
D400 1N4004, 400V 3100.0017 182811 3
D401 1N4004, 400V 3100.0017 182811 3
D402 Rectifier, Bridge, 400V, 25A 3100.0025 182866 3
D403 1N4004, 400V 3100.0017 182811 3
D404 1N4004, 400V 3100.0017 182811 3
D405 1N4004, 400V 3100.0017 182811
D406 1N4004, 400V 3100.0017 182811
D407 1N4004, 400V 3100.0017 182811
D408 1N4004, 400V 3100.0017 182811
D409 1N4004, 400V 3100.0017 182811
D410 1N4004, 400V 3100.0017 182811
D411 1N4004, 400V 3100.0017 182811
D412 1N4004, 400V 3100.0017 182811
D413 1N4004, 400V 3100.0017 182811
D414 1N4004, 400V 3100.0017 182811
D415 1N4004, 400V 3100.0017 182811
Reference
Designator
Description Vendor Part
Number
Bose Part
Number
Note
U400 VOLT REG, +15V, NJM7815FA 3430.0005 262146
U401 VOLT REG, -15V, 7915 3430.0006 262147
U402 VOLT REG, -15V, 7915 3430.0006 262147
U403 VOLT REG, +15V, NJM7815FA 3430.0005 262146
U404 VOLT REG, +15V, NJM7815FA 3430.0005 262146
