5
Features:
• Convection Cooling
• 5-segment LED level display, per channel, including signal present and clip indicators
• 3 LED display, per channel, of power, protect and thermal overload
• Standby LED indicates the amplifier is in standby mode
• Data LED (used with the Bose
®
ACM-1 amplifier control module)
• Level controls can be covered with caps (supplied) to prevent tampering
• Remote control of output level via Euro style connectors
• Standard Dual Input Module with line level inputs via Euro style connectors and XLR jacks,
connected in parallel
• 26 Hz High Pass Filter
• Switched 80 Hz / 120 Hz (12 dB / Octave cut) High Pass Filters
• Switched Clip Limiters
• Terminals for Sequencing Power ON/OFF
• Speaker Output via large gauge Euro style connectors (accepts 12 gauge wire)
• Power Switch, 3 positions, On, Off and Standby
• AC Line Cord (Detachable IEC Type)
• Optional Accessories:
- Computer Control and Monitoring via Bose ACM-1 amplifier control module
Physical Characteristics:
Cooling Method: Convection
Operating Environment: -10 deg C up to 55 deg C, up to 85% RH
Storage Environment: -45 deg C up to 70 deg C, up to 85% RH
Dimensions: 3.5" H (2U) x 19.0" W x 16" D
8.9cm x 48.3cm x 40.6cm
Net Weight: 43 lbs. / 19.5 kgs.
Shipping Weight: 48 lbs. / 21.8 kgs.
Regulatory Information: United States: UL6500, Canada: CAN/CSA
E60065, Europe: EN 60065, Australia/New
Zealand: AS/NZS 3250, Eastern Europe, Far
East, Pacific Rim, Americas and others: IEC
60065 + CB Scheme Certification (Worldwide)
SPECIFICATIONS
MODEL 2150 AMPLIFIER VERSIONS
Description Product Code Voltage
Model 2150 Amplifier, Japan 025985 100V
Model 2150 Amplifier, US/Canada 025986 120V
Model 2150 Amplifier, Euro 025987 220V
Model 2150 Amplifier, UK 025988 230V
Model 2150 Amplifier, Aus 025989 240V
