30
COMPLETE SYSTEM CONNECTIONS
EnglishTAB 6TAB 8 TAB 7 TAB 3TAB 5 TAB 2TAB 4
Connecting the video from your
cable or satellite box first
This connection carries the video from your device to
your TV. You will make the audio connection after this.
1. Locate your cable or satellite box connection
panel.
2. Decide which connector you will use:
a. If a cable still connects the box to your TV, refer
to “Disconnecting your devices from the TV” on
page 25.
Make sure all audio and video cables are discon-
nected from the TV.
Then continue with b.
b. If there is a video cable connected to the cable
box and one end is now free (disconnected from
your TV), use this cable and follow step 5 on
page 31.
c. If the cable box does not have a video cable
attached, notice the type of Video Out connec-
tor the box provides. Then follow steps 3-5.
To Next Page
