ELECTRICAL PART LIST
Resistors
Reference Designator Description Part Number Note
R1 82 OHM, 2512, 1W, 5% 181895-82R0
R2 7.5 OHM, 2512, 1W, 5% 181895-7R5
R11 130 OHM, 2512, 1W, 5% 181895-1300 6
R12 910 OHM, 1206, 1/8W, 5% 124895-9115
R14 2.0K, 2512, 1W, 5% 181895-2001 6
R14 2.7K, 2512, 1W, 5% 181895-2701
R18 330 OHM, 0805, 1/10W, 5% 133626-3315
R19 330 OHM, 0805, 1/10W, 5% 133626-3315
R22 2.2K, 0805, 1/10W, 5% 133626-2225
R23 220 OHM, 1206, 1/8W, 5% 124895-2215
R24 220 OHM, 1206, 1/8W, 5% 124895-2215
R25 4.7K, 0805, 1/10W, 5% 133626-4725
R26 910 OHM, 1206, 1/8W, 5% 124895-9115
R27 10.0K, 0805, 1/10W, 5% 133626-1035
R100 1.00K, 0805, 1/10W, 1% 133625-1001
R101 100K, 0805, 1/10W, 1% 133625-1003
R102 1.00K, 0805, 1/10W, 1% 133625-1001
R103 100K, 0805, 1/10W, 1% 133625-1003
R104 1.00K, 0805, 1/10W, 1% 133625-1001
R105 100K, 0805, 1/10W, 1% 133625-1003
R108 150 OHM, 0805, 1/10W, 1% 133625-1500
R110 150 OHM, 0805, 1/10W, 1% 133625-1500
R111 100K, 0805, 1/10W, 1% 133625-1003
R112 150 OHM, 0805, 1/10W, 1% 133625-1500
R113 100K, 0805, 1/10W, 1% 133625-1003
R116 150 OHM, 0805, 1/10W, 1% 133625-1500
R117 100K, 0805, 1/10W, 1% 133625-1003
R118 150 OHM, 0805, 1/10W, 1% 133625-1500
R119 100K, 0805, 1/10W, 1% 133625-1003
R120 39 OHM, 0805, 1/10W, 5% 133626-3905
R121 1.00K, 0805, 1/10W, 5% 133626-1025 6
R121 10.0K, 0805, 1/10W, 5% 133626-1035
R122 1.00K, 0805, 1/10W, 5% 133626-1025 6
R123 15 OHM, 0805, 1/10W, 5% 133626-1505
R127 1.00K, 0805, 1/10W, 5% 133626-1025
R128 15 OHM, 0805, 1/10W, 5% 133626-1505
R129 750 OHM, 0805, 1/10W, 1% 133625-7500
R130 15 OHM, 0805, 1/10W, 5% 133626-1505
R131 4.7K, 0805, 1/10W, 5% 133626-4725
R132 4.7K, 0805, 1/10W, 5% 133626-4725
R133 3.90K, 0805, 1/10W, 5% 133626-3925
R134 10 OHM, 0805, 1/10W, 5% 133626-1005
R135 2.2K, 0805, 1/10W, 5% 133626-2225
R136 750 OHM, 0805, 1/10W, 1% 133625-7500
R137 3.90K, 0805, 1/10W, 5% 133626-3925
R138 10 OHM, 0805, 1/10W, 5% 133626-1005
R139 2.2K, 0805, 1/10W, 5% 133626-2225
R140 330 OHM, 0805, 1/10W, 5% 133626-3315
R141 330 OHM, 0805, 1/10W, 5% 133626-3315
R142 51.1K, 0805, 1/10W, 0.1% 181896-5112
R143 220 OHM, 0805, 1/10W, 5% 133626-2215
R144 16.9K, 0805, 1/10W, 0.1% 181896-1692
R145 51.1K, 0805, 1/10W, 0.1% 181896-5112
R146 16.9K, 0805, 1/10W, 0.1% 181896-1692
