49
RC-20 REMOTE PART LIST
RC-20 REMOTE ELECTRICAL PART LIST
Reference Designator Description Part Number Note
R1 200 k, 1/10W, 5% 133626-2045
R2 200 k, 1/10W, 5% 133626-2045
R3 200 k, 1/10W, 5% 133626-2045
R4 200 k, 1/10W, 5% 133626-2045
R5 200 k, 1/10W, 5% 133626-2045
R6 200 k, 1/10W, 5% 133626-2045
R7 200 k, 1/10W, 5% 133626-2045
R8 200 k, 1/10W, 5% 133626-2045
R9 430 OHM, 1/10W, 5% 133626-4315
R10 1.k, 1/10W, 5% 133626-1025
R11 47 OHM, 1/10W, 5% 133626-4705
R12 4.7 k, 1/10W, 5% 133626-4725
R13 100 k, 1/10W, 5% 133626-1045
R14 2.43 k, 1/10W, 1% 133625-2431
R15 4.7 k, 1/10W, 5% 133626-4725
R16 470 , 1/10W, 5% 133626-4715
R17 15 k, 1/10W, 5% 133626-1535
R18 5.6 k, 1/10W, 5% 133626-5625
Resistors
(Refer to Figure 9)
Item
Number
Description Part
Number
Qty Per
Assembly
Note
1 PCB Assembly 194386 1 1, 2
2 Pad, Switch, Remote, RC 20,
Audio
178379 1
3 Cover, Bottom, Remote
Control
146089 1
4 Cover, Top, Remote Control,
Universal
176190 1
5 Door, Battery, Remote
Control
146226 1
6 Contact, Battery, Cone 174001 1
7 Contact, Battery, Flat 174000 1
8 Contact, Battery, Cone/Flat 174002-01 1
9 Contact, Battery, Flat/Cone 174002-02 1
10 Spacer, Pad 173605 1
11 Polybag 144348 1
