Bose FreeSpace DXA 2120 User Manual

Installation Guide - 17
Introduction
pro.Bose.com
Included Accessories
Each FreeSpace® DXA 2120 Digital Mixer/Amplifier carton contains one mixer/amplifier and the following
accessories:
Figure 2. FreeSpace® DXA 2120 Digital Mixer/Amplifier carton contents
3-terminal input
connector (4)
4-terminal input
connector (2)
6-terminal input connector
(1)
5-terminal output connector (2) with
screw caps
3-terminal output
connector (1)
Rubber feet
(4)
Rack ears with mounting hardware (2)
Additional Accessories
The following application-specific Bose® accessories are not included with the FreeSpace® DXA 2120
Digital Mixer/Amplifier:
Figure 3. Four volume controllers for use with the FreeSpace® DXA 2120 Digital Mixer/Amplifier
Bose® Volume Control User Interface
is for use when only volume control is
required.
Bose® ControlCenter CC-1 Zone Controller
provides volume control only.
Bose® Volume Control with A/B Select
User Interface is for use in Stereo Select
Mode or Dual Mono Select Mode when
an output provides audio from more than
one input source.
Bose® ControlCenter CC-2 Zone Controller
provides volume control and A/B source
selection.
Connection of one or two user interfaces to the chassis disables the output gain knob for the output
assigned to that user interface.
BA
