Bose S1 PRO+ Service Manual

23
POWER PCB PARTS LIST
Resistors
Reference Designator Description Material Number Note
R1, R6, R97 RES, THICK FILM, 0402, 0.063W, 1%, 47K 801703-4702F
R100, R108, R120, R122 RES, THICK FILM, 0603, 0.1W, 1%, 22 OHM 801706-22R0F
R102, R112 RES, THICK FILM, 0603, 0.1W, 1%, 1 OHM 801707-1R00F
R103, R118 RES, THICK FILM, 0805, 0.125W, 1%, 4.75
OHM
802355-4R75F
R104 RES, THICK FILM, 0402, 0.063W, 1%, 150K 801703-1503F
R105 RES, THICK FILM, 0603, 0.1W, 1%, 270K 801706-2703F
R106 RES, THICK FILM, 0603, 0.1W, 1%, 20K 801706-2002F
R111 RES, THICK FILM, 0603, 0.1W, 1%, 2.2 OHM 801707-2R20F
R12, R15, R22, R25, R40,
R42-R43, R45
RES, THICK FILM, 0402, 0.063W, 1%, 2.2K 801703-2201F
R123, R175 RES, THICK FILM, 0402, 0.063W, 1%, 910K 801703-9103F
R124-R125, R183-R186 RES, THICK FILM, 0603, 0.1W, 1%, 4.7 OHM 801707-4R70F
R130 RES, THICK FILM, 0402, 0.063W, 1%, 120K 801703-1203F
R133 RES, THICK FILM, 0402, 0.063W, 1%, 9.1K 801703-9101F
R134 RES, THICK FILM, 0402, 0.063W, 1%, 3.9K
OHM
801703-3901F
R135 RES, THICK FILM, 0402, 0.063W, 1%, 33K 801703-3302F
R14, R41, R109, R119 JUMPER, CHIP, 0402 806732-0402
R143-R144 RES, THICK FILM, 1206, 0.25W, 1%, 100K 806729-1003F
R145, R147, R149,
R151-R153, R155-R158,
R161-R162
RES, THICK FILM, 0402, 0.063W, 1%, 120
OHM
801703-1200F
R146, R174 RES, THICK FILM, 0402, 0.063W, 1%, 470K 801703-4703F
R150 RES, THICK FILM, 0402, 0.063W, 1%, 12.7K 801703-1272F
R163 RES, THICK FILM, 0402, 0.063W, 1%, 13K 801703-1302F
R17, R31, R93, R114, R117 RES, METAL FOIL, 1206, 1W, 1%, 0.01 OHM 755170-R010F
R176 RES, THICK FILM, 0402, 0.063W, 1%, 68K 801703-6802F
R177 RES, THICK FILM, 0603, 0.1W, 1%, 33K 801706-3302F
R178 RES, THICK FILM, 0603, 0.1W, 1%, 47K 801706-4702F
R18, R26, R34 RES, THICK FILM, 0402, 0.063W, 1%, 20K 801703-2002F
R2, R32, R46, R86 RES, THICK FILM, 0402, 0.063W, 1%, 1K 801703-1001F
R21, R24, R35, R37 RES, THICK FILM, 0603, 0.1W, 1%, 3.3 OHM 801707-3R30F
R23, R141 RES, THICK FILM, 0402, 0.063W, 1%, 470
OHM
801703-4700F
R3, R9, R101 RES, THICK FILM, 0402, 0.063W, 1%, 27K 801703-2702F
R36, R142 RES, THICK FILM, 0402, 0.063W, 1%, 100
OHM
801703-1000F
R38-R39 RES, THICK FILM, 0402, 0.063W, 1%, 3.3
OHM
801704-3R30F
R4, R10, R30, R33, R107,
R136-R139
RES, THICK FILM, 0402, 0.063W, 1%, 10K 801703-1002F

Bose S1 PRO+ Specifications

General

Type	Handheld Public Address (PA) system
Handle(s)	Yes
Product color	Black
Housing material	Aluminium, Polypropylene (PP)
Storage temperature (T-T)	-20 - 49 °C
Operating temperature (T-T)	0 - 45 °C
Bluetooth range	9 m
Bluetooth version	5.0
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	2
Charging time	5 h
AC input voltage	100 - 240 V
Battery capacity	5500 mAh
Power source type	AC, Battery
AC input frequency	50/60 Hz
Battery life (max)	11 h
Number of mixer channels	3 channels
Speaker type	2-way
Number of speakers	-
Frequency range	- Hz
RMS rated power	- W

Weight and Dimensions

Depth	279.8 mm
Width	240 mm
Height	332.6 mm
Weight	6500 g
