Bose S1 PRO+ Service Manual

9
Main Assembly Part List
S1 PRO+ (see Figure 2)
Item
Number
Description Bose Material
Number
Quantity Note
1 TWIDDLER, 2.5IN, NEO, TXX, SVCE 742631-002S
3
4 WOOFER, 6IN, TYMPHANY 789361-001S
1
5 ASSY, PCB, ANTENNA AND CABLE 796036-001S 1
28 GRILLE SUBASSEMBLY, SVCE 866407-001S 1
30 BATTERY, LG, SERVICE 867095-0020 1 3
31 PCB ASSY, POWER, SVCE 867125-002S 1 3
33 INLAY, IO PANEL 867145-0010
1
34 PCB ASSY, POLE SWITCH, SVCE 867157-001S 1
37 FOOT, SIDE, UPPER 867709-0010
1
38 FOOT, SIDE, LOWER 867710-0010
1
40 BASSY, LOGO, SVCE 868338-001S 1
51 FOOT, FRONT, RIGHT 868840-0010
1
52 FOOT, FRONT, LEFT 868841-0010
1
53 FOOT, SIDE, RIGHT 868842-0010 1
54 FOOT, SIDE, LEFT 868843-0010
1
55 FOOT, REAR 868844-0010
1
56 INLAY, BOTTOM, FRONT 868845-0010
1
57 INLAY, BOTTOM, SIDE 868846-0010
2
58 INLAY, BOTTOM, REAR, RIGHT 868847-0010 1
59 INLAY, BOTTOM, REAR, LEFT 868848-0010 1
68 FFC CABLE, 22 PIN, MAIN TO PWR BRD 869441-0010 1
72 FFC CABLE, 24 PIN, MAIN TO DISPLAY-
BRD
869445-0010 1
75 ANTENNA, RF, 270MM LG CABLE 869515-0010 1
76 ANTENNA, RF, 360MM LG CABLE 869515-0020 1
85 PLUG, TRANSMITTER DOCK 872341-0010 2
126 KNOB, VOLUME 841657-0110 3
136 PCB ASSY, DISPLAY, SVCE 867127-001S
1
137 PCB ASSY, MAIN IO, SVCE 867128-003S
1
140 DISPLAY, OLED, FUTABA ELW1104AA 868546-0010 3
141 GASKET, OLED 868705-0010 3
- RUBBER RING 861676-0010 3
Note: For item 137, the PCBA is without the software yet, which can be loaded by polycomm. Using the
.bin le below:
https://hepdsw-web.bose.com/ec/prod/BabyYoda/Release/pro_crescendo_master/3.0.4-728+c67bcd3/
app_babyyoda/encrypted_prod/software_update/

Bose S1 PRO+ Specifications

General

Type	Handheld Public Address (PA) system
Handle(s)	Yes
Product color	Black
Housing material	Aluminium, Polypropylene (PP)
Storage temperature (T-T)	-20 - 49 °C
Operating temperature (T-T)	0 - 45 °C
Bluetooth range	9 m
Bluetooth version	5.0
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	2
Charging time	5 h
AC input voltage	100 - 240 V
Battery capacity	5500 mAh
Power source type	AC, Battery
AC input frequency	50/60 Hz
Battery life (max)	11 h
Number of mixer channels	3 channels
Speaker type	2-way
Number of speakers	-
Frequency range	- Hz
RMS rated power	- W

Weight and Dimensions

Depth	279.8 mm
Width	240 mm
Height	332.6 mm
Weight	6500 g
