Bose S1 PRO+ Service Manual

47
HI-POT TEST
1. Hi-Pot Test
THIS IS A MANDATORY TEST
CAUTION - All units that are disassembled as
part of a repair MUST be Hi-Pot tested before
being returned to the customer.
This test applies a high voltage to the AC line
cord and measures the current leakage to the
chassis and/or other metal parts on the
outside of the unit to check for potential shock
hazards.
If the unit fails Hi-Pot test, it must be returned
to the technician for troubleshooting and repair
of the problem, after which it must be Hi-Pot
tested again.
Hi-Pot Tester Settings:
Type of product: 100-240 VAC 3 wire Class I
Test Voltage: 1592 VAC
Trip Current Limits: 0.5mA min, 10mA max
Ramp: 1 second
Dwell: 3 seconds
Procedure
1.1 Connect the positive side (hot) of the
Hi-Pot tester to both terminals of the AC mains
input.
1.2 Connect the return of the Hi-Pot tester to
the channel 1 to 3 audio connector ground
connections. Pin 1 on the channel 1 and 2
XLR combo jacks, sleeve of 1/8” and 1/4”
inputs and the shell of the Service USB-C
jack.
This test must be performed only after the
system has been completely assembled.
Failure of this test indicates a faulty
transformer, defective or incorrectly dressed
primary wiring, improperly attached leads,
surface contamination of either the power
board or the Main-I/O board, or incorrectly
adjusted trip point on tester.

Bose S1 PRO+ Specifications

General

Type	Handheld Public Address (PA) system
Handle(s)	Yes
Product color	Black
Housing material	Aluminium, Polypropylene (PP)
Storage temperature (T-T)	-20 - 49 °C
Operating temperature (T-T)	0 - 45 °C
Bluetooth range	9 m
Bluetooth version	5.0
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	2
Charging time	5 h
AC input voltage	100 - 240 V
Battery capacity	5500 mAh
Power source type	AC, Battery
AC input frequency	50/60 Hz
Battery life (max)	11 h
Number of mixer channels	3 channels
Speaker type	2-way
Number of speakers	-
Frequency range	- Hz
RMS rated power	- W

Weight and Dimensions

Depth	279.8 mm
Width	240 mm
Height	332.6 mm
Weight	6500 g
