Bose S1 PRO+ Service Manual

4
SAFETY INFORMATION
1. Parts that have special safety characteristics are identied by the symbol on schematics or by
special notes on the parts list. Use only replacement parts that have critical characteristics recommended
by the manufacturer.
2. Make leakage current or resistance measurements to determine that exposed parts are acceptably
insulated from the supply circuit before returning the unit to the customer.
Use the following checks to perform these measurements:
A. Leakage Current Hot Check - With the unit completely reassembled, plug the AC line cord directly
into a 264V (line-neutral), 60Hz power source. (Do not use an isolation transformer during this test.)
Use a leakage current tester or a metering system that complies with American National Standards
Institute (ANSI) UL 101 “Leakage Current for Appliances” and Underwriters Laboratories (UL) 60065/ IEC
60065 Clause 9.1.1.
With the unit Standby switch either in the ON position or OFF position, measure from a known earth
ground (metal waterpipe, conduit, etc.) to all exposed metal parts of the unit (antennas, handle bracket,
metal cabinet, screwheads, metallicoverlays, control shafts, etc.), especially any exposed metal parts
that o󰀨er an electrical return path to the chassis.
Any current measured must not exceed 3.5 mA (or MIU). Reverse the unit power cord plug in the outlet
and repeat test.
ANY MEASUREMENTS NOT WITHIN THE LIMITS SPECIFIED HEREIN INDICATE A POTENTIAL
SHOCK HAZARD THAT MUST BE ELIMINATED BEFORE RETURNING THE UNIT TO THE
CUSTOMER.
B. Insulation Resistance Test Cold Check - (1) Unplug the power supply and connect a jumper wire
between line and neutral blades of the plug.
(2) Measure the resistance with an ohmmeter between the jumpered AC plug and each exposed metallic
cabinet part on the unit. The resistance measured to the metal panel should be between 2 and innite
MOhms. Also, the resistance measured to exposed input/output connectors should be between 4 and
innite MOhms.
If it is not within the limits specied, there is the possibility of a shock hazard, and the unit must be
repaired and rechecked before it is returned to the customer.
PROPRIETARY INFORMATION
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF BOSE
CORPORATION WHICH IS BEING FURNISHED ONLY FOR THE PURPOSE
OF SERVICING THE IDENTIFIED BOSE PRODUCT BY AN AUTHORIZED
BOSE SERVICE CENTER, AND SHALL NOT BE REPRODUCED OR USED
FOR ANY OTHER PURPOSE.
CAUTION: The Bose S1 Pro+ Wireless PA System contains no user-serviceable parts. To prevent war-
ranty infractions, refer servicing to warranty service stations or factory service.

Bose S1 PRO+ Specifications

General

Type	Handheld Public Address (PA) system
Handle(s)	Yes
Product color	Black
Housing material	Aluminium, Polypropylene (PP)
Storage temperature (T-T)	-20 - 49 °C
Operating temperature (T-T)	0 - 45 °C
Bluetooth range	9 m
Bluetooth version	5.0
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	2
Charging time	5 h
AC input voltage	100 - 240 V
Battery capacity	5500 mAh
Power source type	AC, Battery
AC input frequency	50/60 Hz
Battery life (max)	11 h
Number of mixer channels	3 channels
Speaker type	2-way
Number of speakers	-
Frequency range	- Hz
RMS rated power	- W

Weight and Dimensions

Depth	279.8 mm
Width	240 mm
Height	332.6 mm
Weight	6500 g
