Bose S1 PRO+ Service Manual

29
DISPLAY PCB PARTS LIST
Resistors
Capacitors
Diodes
Miscellaneous
Reference Designator Description Material Number Note
R15, R59-R67, R70-R71,
R73-R76
JUMPER, CHIP, 0402 806732-0402
R19-R21 RES, THICK FILM, 0402, 0.063W, 1%, 1.2M 801703-1204F
R1-R2 JUMPER, CHIP, 0603 806732-0603
R24-R26 RES, THICK FILM, 0402, 0.063W, 1%, 100K 801703-1003F
R37-R39, R48-R53 RES, THICK FILM, 0402, 0.063W, 1%, 10K 801703-1002F
R3-R14, R16-R18 RES, THICK FILM, 0402, 0.063W, 1%, 33 OHM 801703-33R0F
Reference Designator Description Material Number Note
C10-C15, C19-C24, C30,
C32-C43, C46-C47,
C50-C53
CAP, X7R, 0402, 50V, 10%, 10000pF, COMM 718866-103K1H
C1-C3, C7-C9 CAP, X5R, 0402, 25V, 10%, 1uF, COMM 716994-105K1E
C4-C6, C16-C18 CAP, X5R, 0603, 25V, 10%, 4.7uF, COMM 718835-475K1E
Reference Designator Description Material Number Note
D1-D9, D15-D17 DIODE, TVS, BIDIR, 5V, 13pF, SOD882 863152-0030
Reference Designator Description Material Number Note
J1 CONN, FPC, 0.5mm C, 24P, 1R, R, SMT, ST 870476-0024
J2-J4 CONN, FFC, 0.3 mm C, 21P, 2R, R, SMT, RA,
ZIF
870525-0021
SW1-SW3 ENCODER, ROTARY, SWITCH, XRE0126 850872-0020

Bose S1 PRO+ Specifications

General

Type	Handheld Public Address (PA) system
Handle(s)	Yes
Product color	Black
Housing material	Aluminium, Polypropylene (PP)
Storage temperature (T-T)	-20 - 49 °C
Operating temperature (T-T)	0 - 45 °C
Bluetooth range	9 m
Bluetooth version	5.0
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	2
Charging time	5 h
AC input voltage	100 - 240 V
Battery capacity	5500 mAh
Power source type	AC, Battery
AC input frequency	50/60 Hz
Battery life (max)	11 h
Number of mixer channels	3 channels
Speaker type	2-way
Number of speakers	-
Frequency range	- Hz
RMS rated power	- W

Weight and Dimensions

Depth	279.8 mm
Width	240 mm
Height	332.6 mm
Weight	6500 g
