Bose S1 PRO+ Service Manual

6
PRODUCT DESCRIPTION
S1 Pro+ Wireless PA System is the next generation of the S1 Pro loudspeaker. Size and weight are sim-
ilar to the S1 Pro. It uses the same input panel/controls form factor as the L1 Pro products and it is also
compatible with Bose Music app.
S1 Pro+ has full ToneMatch and Bluetooth capability.
S1 Pro+ has 2 wireless transmitters for instruments and microphones as options/accessories. The trans-
mitters part numbers are 869721-0010 & 869722-0010.
S1 Pro+ uses the same drivers in the same conguration as S1 Pro.
There are 3 input channels.
Channels 1 and 2 are for instruments and microphones.
Channel 3 is for Bluetooth devices and line-level audio sources.
S1 Pro+ has a battery pack similar to that used on S1 Pro as standard.
S1 Pro+ Specications

Bose S1 PRO+ Specifications

General

Type	Handheld Public Address (PA) system
Handle(s)	Yes
Product color	Black
Housing material	Aluminium, Polypropylene (PP)
Storage temperature (T-T)	-20 - 49 °C
Operating temperature (T-T)	0 - 45 °C
Bluetooth range	9 m
Bluetooth version	5.0
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	2
Charging time	5 h
AC input voltage	100 - 240 V
Battery capacity	5500 mAh
Power source type	AC, Battery
AC input frequency	50/60 Hz
Battery life (max)	11 h
Number of mixer channels	3 channels
Speaker type	2-way
Number of speakers	-
Frequency range	- Hz
RMS rated power	- W

Weight and Dimensions

Depth	279.8 mm
Width	240 mm
Height	332.6 mm
Weight	6500 g
