Bose SoundDock Portable Service Manual

13
ELECTRICAL PART LIST
DSP PCB Assembly
Resistors
Reference
Designator
Description Part Number Note
R7000 10K, 0603, .1W, 1% 191465-1002
R7001 10K, 0603, .1W, 1% 191465-1002
R7002 15K, 0805, .1W, 1% 133625-1502
R7003 15K, 0805, .1W, 1% 133625-1502
R7004 10K, 0603, .1W, 1% 191465-1002
R7006 1M, 0603, .1W, 5% 199403-105
R7007 1M, 0603, .1W, 5% 199403-105
R7008 10K, 0603, .1W, 1% 191465-1002
R7009 10K, 0603, .1W, 1% 191465-1002
R7010 1M, 0603, .1W, 5% 199403-105
R7012 1M, 0603, .1W, 5% 199403-105
R7013 1M, 0603, .1W, 5% 199403-105
R7014 1M, 0603, .1W, 5% 199403-105
R7015 1M, 0603, .1W, 5% 199403-105
R7016 1M, 0603, .1W, 5% 199403-105
R7018 10K, 0603, .1W, 1% 191465-1002
R7019 10K, 0603, .1W, 1% 191465-1002
R7020 10K, 0603, .1W, 1% 191465-1002
R7021 18.2K, 0603, .1W, 1% 191465-1822
R7022 18.2K, 0603, .1W, 1% 191465-1822
R7023 10K, 0603, .1W, 1% 191465-1002
R7024 10K, 0603, .1W, 1% 191465-1002
R7025 150 OHM, 0603, .1W, 1% 191465-1500
R7026 150 OHM, 0603, .1W, 1% 191465-1500
R7052 2.0K, 0603, .1W, 5% 199403-202
R7053 100K, 0603, .1W, 1% 191465-1003
R7054 49.9K, 0603, .1W, 1% 191465-4992
R7055 1.82K, 0603, .1W, 1%, 191465-1821
R7056 1K, 0603, .1W, 1% 191465-1001
R7058 1K, 0603, .1W, 1% 191465-1001
R7077 330 OHM, 0603, .1W, 5% 199403-331
R7078 330 OHM, 0603, .1W, 5% 199403-331
R7082 1K, 0603, .1W, 1% 191465-1001
R7092 18.2K, 0603, .1W, 1% 191465-1822
R7094 10K, 0603, .1W, 1% 191465-1002
R7095 10K, 0603, .1W, 1% 191465-1002
R7122 100 OHM, 0603, .1W, 5% 199403-101
R7143 100 OHM, ARRAY, SMT, 4 POS, 5% 186433-1014
R7146 100 OHM, 0805, .1W, 5% 133626-1015
R7147 100 OHM, 0805, .1W, 5% 133626-1015
R7150 330 OHM, 0603, .1W, 5% 199403-331
R7151 10 OHM, 0603, .1W, 5% 199403-100
R7203 10K, 0603, .1W, 1% 191465-1002
R7208 10K, ARRAY, SMT, 4 POS, 5% 186433-1034
R7209 100K, 0603, .1W, 1% 191465-1003
R7210 100 OHM, 0603, .1W, 5% 199403-101
R7213 100K, 0603, .1W, 1% 191465-1003
R7220 15K, 0603, .1W, 1% 191465-1502

Bose SoundDock Portable Specifications

General

Compatibility	iPhone 3GS 16GB, 32GB, iPhone 3G 8GB, 16GB, iPhone 4GB, iPod touch 1st &2nd gen. 8GB, 16GB, 32GB, iPod classic 80GB, 120GB, 160GB, iPod 5th gen. 30GB, 60GB, 80GB, iPod 4th gen. 20GB, 30GB, 40GB, 60GB, iPod nano 4th gen. 8GB, 16GB, iPod nano 3rd gen. 4GB, 8GB, iPod nano 2nd gen. 2GB, 4GB, 8GB, iPod nano 1st gen. 1GB, 2GB, 4GB, iPod mini 4GB, 6GB.
Product color	Black

Weight and Dimensions

Weight	2370 g
