Bose SoundDock Portable Service Manual

4
SPECIFICATIONS
Electrical
Power Supply Input:
Voltage: 100VAC to 240VAC (universal), 50-60Hz
Current Consumption: 1 A (rms) max for 115VAC
.5 A (rms) max for 230VAC
Power Supply Output:
Voltage: 20V
+/- 1V DC
Current: 2A (max)
SoundDock
®
Input:
Voltage: 20V, +/- 1V
DC
Current Consumption: 2 Amp (max, continuous)
Power Consumption: 40W (max, continuous)
Acoustic
Drivers: 2 - 2.25” Full Range Twiddler™ speakers
Nominal Impedance: 2.2 Ohms
Port Tuning: 65 HZ
Physical Description
Mechanical Specifications: Battery attached, Dock open
6.59”H x 12.08”W x 5.75”D (16.73 cm x 30.68 cm x 14.60 cm)
Weight: System with Battery attached
4.45 lb (2.0 kg)
Enclosure: Ultrasonically welded PC/ABS plastic

Bose SoundDock Portable Specifications

General

Compatibility	iPhone 3GS 16GB, 32GB, iPhone 3G 8GB, 16GB, iPhone 4GB, iPod touch 1st &2nd gen. 8GB, 16GB, 32GB, iPod classic 80GB, 120GB, 160GB, iPod 5th gen. 30GB, 60GB, 80GB, iPod 4th gen. 20GB, 30GB, 40GB, 60GB, iPod nano 4th gen. 8GB, 16GB, iPod nano 3rd gen. 4GB, 8GB, iPod nano 2nd gen. 2GB, 4GB, 8GB, iPod nano 1st gen. 1GB, 2GB, 4GB, iPod mini 4GB, 6GB.
Product color	Black

Weight and Dimensions

Weight	2370 g
