Bose T1 ToneMatch User Manual

31
OPERATING INSTRUCTIONS
SvenskaItalianoFrançaisEspañolDeutschDanskEnglish Nederlands
• USB from PC – Allows you to send USB left and right channels from your computer to a selected audio
engine destination (Off, Ch4/5, or Master). If the destination is Ch4/5, the USB audio is inserted into chan-
nels 4/5 directly after the trim control and can be fully processed. The channel 4/5 analog inputs remain
operational.
• Master Out – Allows you to configure the Master output as a pre- or post-master volume control output.
USB from PC Preferences
Left: Off
Right: Off
Menu Left Right
1. Rotate the Left/Right button to highlight a destination: Off, Ch4/5, or
Master.
2. Press the Select button to select the destination, or press the Cancel
button to exit with no change.
3. Press Menu to return to the Prefs menu list.
Master Out Preferences
Source:
Post Master Volume
Menu Select
1. Rotate the Select button to highlight your choice: Post Master
Volume or Pre Master Volume.
2. Press the Select button to select the setting, or press the Cancel
button to exit with no change.
3. Press the Menu button to return to the Prefs menu list.

Bose T1 ToneMatch Specifications

General

Sample rate	48 kHz
Channels quantity	- channels
Digital sound processing	- bit
DJ mixer	-
Backlight	Yes
Backlight color	Blue
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Depth	208.9 mm
Width	165.5 mm
Height	67.6 mm
Weight	970 g
