Breas Vivo 3 User Manual

With Humidifier
1
2
3
4
5
6
Number Description
1
Air inlet (Ambient room air intake)
2 Blower
3 Sensors
4
Humidifier
5
Air outlet (Breathing air to the
patient)
6
Cartridge heater
The humidification output is controlled by the ventilator by regulating the power to the
cartridge heater in the humidifier.
9.5 Technical Data
Noise Levels
Property Value
Static sound pressure level
< 27.8 dB(A) @ 10 cmH
2
O, 4 mm leak.
Measured at a distance of 1 meter, according
to standard.
Static sound pressure level, stand by
mode
< 22 dB(A) SPL.
Measured at a distance of 1 meter, according
to standard.
Technical Specifications 117
Doc. 007229 D-3 User manual

Breas Vivo 3 Specifications

General

Brand	Breas
Model	Vivo 3
Category	Medical Equipment
Language	English
