1. SPECIFICATIONS LIST
1.1 General
Model
DCP-8110D
DCP-8110DN
DCP-8112DN
DCP-8150DN
DCP-8152DN
DCP-8155DN
DCP-8157DN
DCP-8250DN
MFC-8510DN
MFC-8512DN
MFC-8515DN
Print method Electrophotographic Laser Printer
Resolution
1200 x 1200 dpi, HQ1200 (2400 x 600 dpi), 600 x 600 dpi
Print speed One-sided Up to 36/38
ppm (A4/
Letter size)
Up to 40/40 ppm (A4/Letter size)
DCP-8155DN For Asia and Oceania /
DCP-8250DN:Up to 40/42 ppm (A4/
Letter size)
Up to 36/38
ppm (A4/
Letter size)
Two-sided 18/18 sides per minute (9/9 sheets per minute) (A4/Letter size)
Warm-up
time
From Sleep
mode
Less than 3 seconds at 73.4F / 50% (23°C / 50%)
From Power
OFF → ON
Less than 27 seconds at 73.4F / 50% (23°C / 50%)
First print
time
From Ready
mode
Less than 8.5 seconds
From Sleep
mode
Less than 10 seconds
CPU StarSapphire 400 MHz
Memory Standard 64 MB 128 MB 64 MB
Option Up to 256 MB (DDR2 16 bit, 144 pin)
Interface Hi-Speed USB 2.0
10Base-T/100Base-TX (DCP-8110D:
N/A)
Hi-Speed USB 2.0
10Base-T/100BaseTX/
1000Base-T (DCP-8250DN only)
Power
consumption
Peak Average: Approximately 1200 W
Copying
Average:
Approximately
669 W (for
U.S.A.)
Average:
Approximately
651 W (for
Europe, Asia)
Average: Approximately 702 W
(for U.S.A.)
Average: Approximately 694 W
(for Europe, Asia, Oceania)
Average:
Approximately
669 W (for
U.S.A.)
Average:
Approximately
651 W (for
Europe, Asia,
Oceania, China)
Quiet Mode/
Copying
Average:
Approximately
336 W
Average: Approximately 350 W Average:
Approximately
336 W
Ready Average: Approximately 8.1 W
Sleep, Wireless
LAN: ON
N/A
Deep Sleep
Average:
Approximately
1.2 W
Average: Approximately
1.4 W
Average:
Approximately
1.6 W
Average:
Approximately
1.2 W
Auto Power
Down Mode
Approximately 0.26 W (only for
Europe and GULF)
Approximately
0.45W (only
for Europe and
GULF)
N/A
Specifications are subject to change without notice.

Brother DCP-8150DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Time to first copy (black, normal)	10.5 s
Scan to	E-mail, File, FTP, Image, OCR, USB
Scan drivers	ICA, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	Legal (216 x 356) mm
Output color depth	24 bit
Maximum scan resolution	19200 x 19200 DPI
Faxing	No
Printing colors	Black
Maximum duty cycle	50000 pages per month
Recommended duty cycle	500 - 3500 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Thick paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
JIS B-series sizes (B0...B9)	B5
Duplex media weight (imperial)	16 - 28 lbs
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Paper tray media weight (imperial)	16 - 43 lbs
Display	LCD
Market positioning	Business
Display number of lines	5 lines
Display number of characters	22
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print
Maximum internal memory	320 MB
Sound power level (standby)	37 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1.4 W
Power consumption (PowerSave)	8.1 W
Power consumption (average operating)	702 W
Package depth	533.4 mm
Package width	594.36 mm
Package height	604.52 mm
Package weight	19800 g
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Starter, Windows 7 Ultimate, Windows Vista Business, Windows Vista Enterprise, Windows Vista Home Basic, Windows Vista Home Premium, Windows Vista Ultimate, Windows XP Home, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	414.02 mm
Width	490.22 mm
Height	447.04 mm
