Brother DCP-8150DN Service Manual

5-1
Confidential
1. MAINTENANCE MODE
Maintenance mode is exclusively designed for checking, setting and adjusting the machine
using the buttons on the control panel.
Using maintenance mode functions, you can conduct operational checks of sensors or test
printing, display the log information or error codes, and change the worker switches (WSW) etc.
1.1 How to Enter Maintenance Mode
1.1.1 Method of entering end-user accessible maintenance mode
Basically, the maintenance mode functions should only be accessed by service personnel.
However, end users are allowed to use some of these functions under the guidance of service
personnel over the phone. End users can only use the functions shaded in the table on the on
page 5-2 (function codes 06, 09, 10, 11, 12, 25, 43, 45, 52, 53, 54, 61, 77, 80, 82, 87, 88 and
91).
<Operating Procedure>
1.1.2 Method of entering maintenance mode for service personnel
<Operating Procedure>
Non touch panel models
(1) While the machine is in the ready state,
press the [Menu], [Start], and [Menu]
buttons in this order.
"0" is displayed on the LCD.
(2) Use the keypad to enter the
maintenance mode function code to be
executed.
(3) Each time the selected maintenance
mode function is completed, the
machine returns to the ready state
automatically.
Touch panel models
(1) While the machine is in the ready state,
press the [Menu], [Start], and [0]
buttons in this order.
"0" is displayed on the LCD.
(2) Use the keypad to enter the
maintenance mode function code to be
executed.
(3) Each time the selected maintenance
mode function is completed, the
machine returns to the ready state
automatically.
Non touch panel models
(1) While the machine is in the ready state,
press the [Menu] and [Start] buttons in
this order. Then, press the [ ] button
four times to enter maintenance mode.
(2) "
  MAINTENANCE    " is displayed
on the LCD to indicate that the machine
has moved into the initial state of
maintenance mode. The machine is
ready to accept entry via the buttons.
(3) To select any of the maintenance mode
functions shown in the list on the next
page, use the keypad to enter the
maintenance mode function code to be
executed.
Touch panel models
(1) While the machine is in the ready state,
press the [Menu] and [*] buttons in this
order. Then, press the [2], [8], [6], and
[4] buttons in this order to enter
maintenance mode.
(2) "
  MAINTENANCE    " is displayed
on the LCD to indicate that the machine
has moved into the initial state of
maintenance mode. The machine is
ready to accept entry via the buttons.
(3) To select any of the maintenance mode
functions shown in the list on the next
page, use the keypad to enter the
maintenance mode function code to be
executed.

Brother DCP-8150DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Time to first copy (black, normal)	10.5 s
Scan to	E-mail, File, FTP, Image, OCR, USB
Scan drivers	ICA, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	Legal (216 x 356) mm
Output color depth	24 bit
Maximum scan resolution	19200 x 19200 DPI
Faxing	No
Printing colors	Black
Maximum duty cycle	50000 pages per month
Recommended duty cycle	500 - 3500 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Thick paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
JIS B-series sizes (B0...B9)	B5
Duplex media weight (imperial)	16 - 28 lbs
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Paper tray media weight (imperial)	16 - 43 lbs
Display	LCD
Market positioning	Business
Display number of lines	5 lines
Display number of characters	22
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print
Maximum internal memory	320 MB
Sound power level (standby)	37 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1.4 W
Power consumption (PowerSave)	8.1 W
Power consumption (average operating)	702 W
Package depth	533.4 mm
Package width	594.36 mm
Package height	604.52 mm
Package weight	19800 g
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Starter, Windows 7 Ultimate, Windows Vista Business, Windows Vista Enterprise, Windows Vista Home Basic, Windows Vista Home Premium, Windows Vista Ultimate, Windows XP Home, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	414.02 mm
Width	490.22 mm
Height	447.04 mm
