Brother DCP-8150DN Service Manual

2-28
Confidential
3.3 Communication Errors
Code 1 Code 2 Cause
Refer
to.
10 07 No document set when calling. 2-96
10 08 Wrong fax number called. 2-96
11 01 No dial tone detected before dialing. 2-96
11 02 Busy tone detected before dialing. 2-96
11 03 2nd dial tone not detected. 2-96
11 05 No loop current detected. 2-96
11 06 Busy tone detected after dialing or called. 2-96
11 07 No response from the remote station in sending. 2-96
11 10 No tone detected after dialing. 2-96
11 11
No acknowledgement returned after Fax2 net command
was sent.
2-96
17 01
Called using a dial number that cannot be used for the
NGN line (33 digits or longer or non numeric characters).
2-96
17 07 No response from the remote station in receiving. 2-96
1C 01
Detected that access to the NGN line was not authorized.
(T38: 403 Forbidden)
2-96
1C 02
No file or folder (directory) found as a result of search via
the NGN line. (T38: 404 Not Found)
2-96
1C 03
Remote station does not support the NGN line. (T38: 488
Not Acceptable Here)
2-96
1C 04
SIP (Session Initiation Protocol) connection not possible.
(T38)
USW NGN fax setting is OFF or calling attempted before
acquisition of SIP information.
2-96
1C 05
Internal error detected in the communication network.
(T38)
2-96
1C 06 SIP Server timeout (T38) 2-96
1C 08
An error other than 1C01, 1C02, 1C03, 1C04, 1C06, 1D01,
1D02 and 1D04 was detected.
2-96
1D 01 Detected that the NGN line was busy. (T38: 486 Busy) 2-96
1D 02
Detected that the NGN line was temporarily unavailable.
(T38: 480 Temporarily Unavailable)
2-96
1D 04
Network cable not connected (Link Down detected) or not
connected to the Network. (T38)
2-96
20 01 Unable to detect flag field. 2-96
20 02 Carrier was OFF for 200 ms or longer. 2-96
20 03 Abort detected ("1" in succession for 7 bits or more). 2-96
20 04 Overrun detected. 2-96
20 05 A frame received for 3 seconds or more. 2-96
20 06 CRC error in answerback. 2-96
20 07 Echo command received. 2-96
20 08 Invalid command received. 2-96
20 09
Command ignored once for document setting or for
damping-out at turn-around transmission.
2-96
20 0A T5 time-out error 2-96
20 0B CRP received. 2-96
20 0C EOR or NULL received. 2-96

Brother DCP-8150DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Time to first copy (black, normal)	10.5 s
Scan to	E-mail, File, FTP, Image, OCR, USB
Scan drivers	ICA, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	Legal (216 x 356) mm
Output color depth	24 bit
Maximum scan resolution	19200 x 19200 DPI
Faxing	No
Printing colors	Black
Maximum duty cycle	50000 pages per month
Recommended duty cycle	500 - 3500 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Thick paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
JIS B-series sizes (B0...B9)	B5
Duplex media weight (imperial)	16 - 28 lbs
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Paper tray media weight (imperial)	16 - 43 lbs
Display	LCD
Market positioning	Business
Display number of lines	5 lines
Display number of characters	22
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print
Maximum internal memory	320 MB
Sound power level (standby)	37 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1.4 W
Power consumption (PowerSave)	8.1 W
Power consumption (average operating)	702 W
Package depth	533.4 mm
Package width	594.36 mm
Package height	604.52 mm
Package weight	19800 g
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Starter, Windows 7 Ultimate, Windows Vista Business, Windows Vista Enterprise, Windows Vista Home Basic, Windows Vista Home Premium, Windows Vista Ultimate, Windows XP Home, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	414.02 mm
Width	490.22 mm
Height	447.04 mm
