Brother DCP-8150DN Service Manual

5-19
Confidential
1.3.12 Set PC print functions (function code: 43)
<Function>
This function is used to change the settings of the various print functions summarized in the
table below.
<Operation Procedure>
(1) Press the [4] and [3] buttons in this order in the initial state of maintenance mode. "Manual
Feed" is displayed on the LCD.
(2) Press the [ ] or [ ] button to display the function you want to change the setting of,
and press the [OK] button.
(3) For fixed parameters (On/Off, etc.), press the [ ] or [ ] button to display the setting
you want to apply, and press the [OK] button. The setting is saved.
For parameters requiring numerical value entry, use the keypad to enter a numerical
value, and press the [OK] button. The setting is saved.
(4) Press the [Stop/Exit] button to return the machine to the initial state of maintenance
mode.
 Setting functions
LCD Description Set value Default
Manual Feed Manual feed setting On/Off Off
Resolution Print resolution 300/600/1,200 dpi 600 dpi
Toner Save Toner save mode setting On/Off Off
Density Print density level -6 to 6 0
JB-Can Time Time until host timeout is
triggered when job is cancelled
0 to 225 (s) 4 (s)
Sleep Time Time until sleep mode is entered 0 to 99 (min) 5 (min)
Page Protection Page memory setting Off/Letter/A4/Legal/Auto Off
Emulation Emulation (print language)
setting
Auto/HP/PS Auto
Auto I/F Time Interface open time 1 to 99 (s) 5 (s)
Media Type Paper type setting Thin/Plain/Thick/
Thicker/Trancparency/
Recycled/Bond/
Envlopes/EnvThin/
EnvThick
Plain or Thin
Paper Size Image development area setting Letter/Legal/A4/
Executive/B5/JISB5/A5/
B6/A6/Monarch/C5/
COM10/DL/DLL/
A4Long/PostCard/Folio
Letter or A4
Copies Number of copies 1 to 99 (copies) 1 (copies)
Orientation Print direction setting Portrait/Landscape Portrait
P-Pos X-Offset Print position offset in X
(landscape) direction
-500 to 500 (1/300 dpi) 0 (1/300 dpi)
P-Pos Y-Offset Print position offset in Y (portrait)
direction
-500 to 500 (1/300 dpi) 0 (1/300 dpi)
AutoFF Auto form feed setting On/Off Off
AutoFF Time Timeout period of auto form feed 1 to 99 (s) 5 (s)
FF Surpress Blank page skip setting On/Off Off
Auto LF Auto linefeed (LF) setting On/Off Off
Auto CR Auto carriage return (CR) setting On/Off Off
Auto WRAP Setting for Auto CRLF at print
width
On/Off Off

Brother DCP-8150DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Time to first copy (black, normal)	10.5 s
Scan to	E-mail, File, FTP, Image, OCR, USB
Scan drivers	ICA, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	Legal (216 x 356) mm
Output color depth	24 bit
Maximum scan resolution	19200 x 19200 DPI
Faxing	No
Printing colors	Black
Maximum duty cycle	50000 pages per month
Recommended duty cycle	500 - 3500 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Thick paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
JIS B-series sizes (B0...B9)	B5
Duplex media weight (imperial)	16 - 28 lbs
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Paper tray media weight (imperial)	16 - 43 lbs
Display	LCD
Market positioning	Business
Display number of lines	5 lines
Display number of characters	22
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print
Maximum internal memory	320 MB
Sound power level (standby)	37 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1.4 W
Power consumption (PowerSave)	8.1 W
Power consumption (average operating)	702 W
Package depth	533.4 mm
Package width	594.36 mm
Package height	604.52 mm
Package weight	19800 g
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Starter, Windows 7 Ultimate, Windows Vista Business, Windows Vista Enterprise, Windows Vista Home Basic, Windows Vista Home Premium, Windows Vista Ultimate, Windows XP Home, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	414.02 mm
Width	490.22 mm
Height	447.04 mm
