LED display
The condition of the printer can be determined by LED display on printer or USB Direct Interface (PT-
9800PCN only).
■ LED display on printer
Lamp condition
Condition Remedy
Power button
(green)
STATUS lamp
(red)
Lit Not lit Printer standby condition —
Flashing Not lit Receiving data —
Flashing Lit
During the printer receiving data
1) No tape cassette 1) Install the tape cassette and
close the tape compartment
cover.
2) Tape compartment cover is
open.
2) Close the cover.
3) Incompatible tape cassette 3) Install the correct tape cassette
and close the tape compartment
cover.
Lit Lit
During the printer standby
1) No tape cassette 1) Install the tape cassette and
close the tape compartment
cover.
2) Tape compartment cover is
open.
2) Close the cover.
3) Incompatible tape cassette 3) Install the correct tape cassette
and close the tape compartment
cover.
Lit Flashing
During printing
1) No tape cassette 1) Install the tape cassette and
close the tape compartment
cover.
2) Tape compartment cover is
open.
2) Close the cover.
3) Incorrect tape cassette 3) Install the correct tape cassette
and close the tape compartment
cover.
4) Incompatible tape cassette 4) Install the correct tape cassette
and close the tape compartment
cover.
Empty tape cassette
Install a tape cassette containing
tape and close the tape
compartment cover.
Transmission error
Press the power button on the front
of the printer.
PT9700PC9800PCN_US.book Page 12 Wednesday, October 7, 2009 11:58 AM

Brother P-touch PT-9700PC Specifications

General

Print technology	Direct thermal
Vertical printing	Yes
Maximum resolution	720 x 360 DPI
Product color	White
Keyboard layout	ABC
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Minimum storage drive space	70 MB
Compatible operating systems	Microsoft Windows 2000 Prof. (SP4), XP, Vista, Windows 7, Mac OS X 10.4 - 10.6
Tape size	36 mm
Label type	TZ / AL / HZ
Power supply type	AC adaptor (AD9100ES) (Enclosed)
Print sizes included	20
Maximum label length	1 m
Tape cutting	Automatic
Number of styles	10
Built-in barcodes	POSTNET, UPC-A, UPC-E
Bundled software	P-touch Editor 5.0
Package weight	3.190 g

Weight and Dimensions

Depth	193 mm
Width	116 mm
Height	140 mm
