Brother P-touch PT-9700PC User Manual

20
5
When instructed, connect your printer to
the computer by using the USB cable,
and then turn on the printer.
6
Once the printer is detected, the driver
will automatically be installed.
7
When instructed to register your printer
online, select a registration method and
click [Next].
If you have selected to register the
product online, your default internet
browser will be launched in a new
window.
8
When instructed to download the
optional tools, select your choice and
click [Next].
• If you choose “Yes, display the page”,
you will go to the web site “solutions
center” page before finishing the
installation. (recommended)
[Select your region/country]-[Choose
your product]-[Downloads]
• If you choose “No, do not display the
page”, you will continue the
installation.
9
Click [Finish].
The software installation is now complete.
Restart your computer if you are
instructed to do so.
0
Start the software.
Click “Start” - “All Programs (Programs)” -
“Brother P-touch” - “P-touch Editor 5.0”
to start P-touch Editor 5.0.
When using Mac OS
®
This section explains how to install P-touch
Editor 5.0 and printer driver.
Below is the example for Mac OS
®
X 10.5.7.
1
Start up Macintosh
®
, and insert the CD-
ROM into the CD-ROM drive.
Double click the “PT_Series” (CD-ROM)
icon.
2
Double click “Brother PT-9700PC
Driver.pkg” in “Mac OS X” folder.
The Driver Installer starts up. Follow the
on-screen instructions.
Note
● To download the optional tools later, you
can find them on this Web site:
http://solutions.brother.com/
[Select your region/country] - [Choose
your product] - [Downloads]
DC IN 24V
USB port
USB cable
AC adapter jack
AC adapter
Note
● Until P-touch Editor 5.0 installation is
completed, do not connect the printer to
Macintosh
®
. Make sure the USB cable is
not connected until you are instructed to
connect it.
● You must be logged on as a user with
administrator privileges to install this
software.
● Turn off the printer with the power button
and then with the main power switch.
PT9700PC9800PCN_US.book Page 20 Wednesday, October 7, 2009 11:58 AM

Brother P-touch PT-9700PC Specifications

General

Print technology	Direct thermal
Vertical printing	Yes
Maximum resolution	720 x 360 DPI
Product color	White
Keyboard layout	ABC
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Minimum storage drive space	70 MB
Compatible operating systems	Microsoft Windows 2000 Prof. (SP4), XP, Vista, Windows 7, Mac OS X 10.4 - 10.6
Tape size	36 mm
Label type	TZ / AL / HZ
Power supply type	AC adaptor (AD9100ES) (Enclosed)
Print sizes included	20
Maximum label length	1 m
Tape cutting	Automatic
Number of styles	10
Built-in barcodes	POSTNET, UPC-A, UPC-E
Bundled software	P-touch Editor 5.0
Package weight	3.190 g

Weight and Dimensions

Depth	193 mm
Width	116 mm
Height	140 mm
