Brother P-touch PT-9700PC User Manual

35
Distributed printing
When printing a large number of labels,
printing can be distributed among multiple
printers.
Since printing is performed at the same time,
the total printing time can be reduced.
1
From the “File” menu in P-touch Editor
5.0, click “Print”.
2
Click [Properties...].
3
Select the “Advanced” tab, select the
“Distributed printing” check box, and
then click [Settings].
4
In the “Distributed Printing Settings”
dialog box, select the printers to be used
for distributed printing.
1. Click [Detect Current Paper
Information...].
2. The current printer information that
was detected appears below “Current
Width” and “Paper Type”.
3. Select the check box beside the “Printer
Name” to be used for distributed
printing.
Note
● Printing can be distributed to printers
connected via a USB connection or
network connection (PT-9800PCN only).
● The number of pages to be printed is
automatically divided among the selected
printers. If the specified number of pages
cannot be evenly divided among the
printers, it will be divided in the order of
the printers listed in the dialog box when
the print settings are specified in step
4.
67 67
66
200
3
1
2
PT9700PC9800PCN_US.book Page 35 Wednesday, October 7, 2009 11:58 AM

Brother P-touch PT-9700PC Specifications

General

Print technology	Direct thermal
Vertical printing	Yes
Maximum resolution	720 x 360 DPI
Product color	White
Keyboard layout	ABC
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Minimum storage drive space	70 MB
Compatible operating systems	Microsoft Windows 2000 Prof. (SP4), XP, Vista, Windows 7, Mac OS X 10.4 - 10.6
Tape size	36 mm
Label type	TZ / AL / HZ
Power supply type	AC adaptor (AD9100ES) (Enclosed)
Print sizes included	20
Maximum label length	1 m
Tape cutting	Automatic
Number of styles	10
Built-in barcodes	POSTNET, UPC-A, UPC-E
Bundled software	P-touch Editor 5.0
Package weight	3.190 g

Weight and Dimensions

Depth	193 mm
Width	116 mm
Height	140 mm
