z GETTING STARTED
Power Supply
Battery
Turn the P-touch labeler over and remove the
battery compartment cover. If the batteries are
already in the machine, remove them.
Insert six new AA-size alkaline batteries (LR6),
making sure that the positive (+) and negative (-)
ends of the batteries match the positive (+) and
negative (-) marks inside the battery compartment.
23
Attach the battery compartment cover by inserting
the three hooks at the bottom into the slots on the
machine, then pushing down firmly until it snaps
into place.
Power Supply
If you are replacing the batteries please ensure
that the labeler is turned off prior to opening
the battery compartment.
1
Always replace all six batteries at the same
time using brand new ones.
2
3
CAUTION
If you do not intend to use the P-touch labeler for an extended period of time it is
recommended that the batteries be removed.
