Brother PT-2700 User Manual

10
LCD Display & Keyboard
GETTING STARTED
LCD Display
1. Line number
Displayed at the beginning of each line, this mark indicates the line number within
the label layout.
2. Cursor
Indicates the current position of the cursor. New characters are entered to the left of
the cursor, and the character to the left of the cursor is deleted when the key is
pressed.
3. Return mark
Indicates the end of a line of text.
4. Caps mode
Indicates that the Caps mode is on.
5.~8. Style guidance
Indicates the current font (5), character size (6), character style (7), frame (8)
settings.
9. Tape length
Indicates the tape length for the text entered.
10.Cursor selection
Indicates that you can use the cursor keys to select the items on the screen. Use
the and keys to select a menu item, and the and keys to change the
setting.
LCD Display & Keyboard
1
2
456789 10
3
Refer to "LCD Display" on page 21 for changing the contrast and display mode, and for turning
the back light on/off.

Brother PT-2700 Specifications

General

Model	PT-2700
Print Technology	Thermal Transfer
Maximum Print Resolution	180 dpi
Maximum Print Speed	10 mm/sec
Keyboard	QWERTY
Cutter	Automatic
Tape Widths	6mm, 9mm, 12mm, 18mm
Display	16 characters x 3 lines
Connectivity	USB
Power Source	AC adapter
Styles	Normal, Bold, Outline, Shadow, Italic
Label Cassette	24mm
Type	Desktop Label Maker
