z EDITING A LABEL
Creating a Bar Code Label
zBar Code Settingsz
Entering Bar Code Data
Press the key to display the Setup menu, select
"Bar Code Input" using the or keys, and then
press the or key.
The Bar Code Input screen is displayed.
Type in the bar code data.
Special characters can be entered in the bar code
when using the CODE39, CODABAR, CODE128 or
EAN128 protocols. When not using special characters,
go to step 5.
Press the key.
A list of characters available for the current protocol is
displayed.
Select a character using the or keys, then press
the or key to insert the character in the bar code
data.
Attribute Value
Protocol
CODE39 , CODE128, EAN8, EAN13, EAN128,
UPC-A, UPC-E, I-2/5 (ITF), CODABAR
Width
Large
Small
Under#
(characters printed
below bar code)
On
Off
C.Digit
(check digit)
Off
On
(only available for the CODE39, I-2/5
and CODABAR protocols)
• Up to five bar codes can be entered in a label.
• Pressing key while holding down key
will also allow you to go to "Bar Code Input".
1
2
3
4

Brother PT-2700 Specifications

General

Model	PT-2700
Print Technology	Thermal Transfer
Maximum Print Resolution	180 dpi
Maximum Print Speed	10 mm/sec
Keyboard	QWERTY
Cutter	Automatic
Tape Widths	6mm, 9mm, 12mm, 18mm
Display	16 characters x 3 lines
Connectivity	USB
Power Source	AC adapter
Styles	Normal, Bold, Outline, Shadow, Italic
Label Cassette	24mm
Type	Desktop Label Maker
