z GETTING STARTED
Inserting a Tape Cassette
Tape cassettes of 3.5mm, 6mm, 9mm, 12mm, 18mm, 24mm width can be used in your
P-touch. Use only tape cassettes with the mark.
Check that the end of the tape is not bent and
that it passes through the tape guide.
After making sure that the power is off, lift open the
tape compartment cover. If there is already a tape
cassette in the machine, remove it by pulling it
straight up.
Insert the tape cassette into the tape
compartment, with the end of the tape
facing the machine's tape exit slot, and
press firmly until you hear a click.
Inserting a Tape Cassette
If the new tape cassette has a cardboard stopper, be sure to remove
the stopper before inserting the cassette.
WATNLATION
End of tape
Tape guide
1
2
When inserting the tape cassette,
make sure that the tape and ink
ribbon do not catch on the print head.
Tape exit slot
3

Brother PT-2700 Specifications

General

Model	PT-2700
Print Technology	Thermal Transfer
Maximum Print Resolution	180 dpi
Maximum Print Speed	10 mm/sec
Keyboard	QWERTY
Cutter	Automatic
Tape Widths	6mm, 9mm, 12mm, 18mm
Display	16 characters x 3 lines
Connectivity	USB
Power Source	AC adapter
Styles	Normal, Bold, Outline, Shadow, Italic
Label Cassette	24mm
Type	Desktop Label Maker
