z USING THE FILE MEMORY
Opening a Stored Label File
Press the key to display the File screen.
Select "Open" using the or keys.
Press the or key.
The file number of a stored label is displayed.
The label text is also displayed to identify the label.
Select a file number using the or key, and then
press the or key to open the selected file.
The file is opened and displayed on the text entry
screen.
Opening a Stored Label File
1
2
3
4
Press the key to return to the previous step.

Brother PT-2700 Specifications

General

Model	PT-2700
Print Technology	Thermal Transfer
Maximum Print Resolution	180 dpi
Maximum Print Speed	10 mm/sec
Keyboard	QWERTY
Cutter	Automatic
Tape Widths	6mm, 9mm, 12mm, 18mm
Display	16 characters x 3 lines
Connectivity	USB
Power Source	AC adapter
Styles	Normal, Bold, Outline, Shadow, Italic
Label Cassette	24mm
Type	Desktop Label Maker
