124 External Connections
NOTES
• Power the camcorder using the compact power adapter and only then
connect it to the computer using the supplied USB cable in the follow-
ing cases.
- To write back scenes recorded with this camcorder that were
previously saved on a computer.
- To transfer music files from the supplied Camcorder Supplemental
Disc in order to use them as background music.
Connection c
Composite Video (SCART)
In all respects, exactly the same connection as connection C.
Connect to a standard TV or VCR with SCART input terminal. Requires a SCART adapter
(commercially available).
Connection D
USB
Type: Digital data connection
Connect to a computer to save your recordings, to the optional DW-100 DVD Burner to
create DVD discs from them, or to a printer to print out photos.
STV-250N Stereo Video Cable
(supplied)
SCART adapter
(commercially available)
Yellow
White
Red
USB Cable
(supplied)
To Next Page
