64 • External Connections
Connection Diagrams
In the following connection diagrams, the left side shows the terminals on the
camcorder and the right side shows (for reference only) an example of terminals on a
connected device.
* Users of Windows Vista, Windows XP and Mac OS X: Your camcorder is equipped with
the standard Picture Transfer Protocol (PTP) allowing you to transfer still images (JPEG
only) by connecting the camcorder to a computer using the supplied USB cable.
Connection
Type: Analog Output only
Connect to a TV or VCR with audio/video input terminals.
- Change the [TV TYPE] setting according to the TV set (widescreen or 4:3), if the TV
cannot automatically detect and change the aspect ratio ( 72).
Connection
Type: Digital data connection
Connect to a PictBridge-compatible printer to print out your still images*.
1
VIDEO
AUDIO
R
L
STV-250N Stereo Video Cable
(supplied)
Yellow
White
Red
2
USB Cable
(supplied)
To Next Page
