Canon ImagePrograf iPF840 series User Manual

Printer parts
Printer parts
Front ............................................................................................................................................................... 67
Back ............................................................................................................................................................... 69
Top Cover (Inside) ........................................................................................................................................... 70
Carriage .......................................................................................................................................................... 71
Ink Tank Cover (Inside) .................................................................................................................................... 72
Front
Front
r
j
o
q
m
p
n
q
a
i
h
b
l
k
l
c
c
g
s
g
d
d
e
f
a
Top Cover
Open this cover to install the Printhead, load paper, and remove any jammed paper from inside the printer as
needed. (See "Top Cover (Inside).") ➔P.70
b
Ejection Guide
Guides printed documents as they are ejected. Open this guide when loading a roll.
c
Roll Holder Slot
Slide the Roll Holder into this slot.
d Roll Holder
Load the roll on this holder.
e Roll Unit Lever
Hold this lever to pull out the Roll Unit.
iPF840 Series
Front
Basic Guide
Printer Parts Printer parts
