Chapter 3
3-29
3.5.3.4 Removing the Upper Cover
0008-3603
1) Free the link stop [2] from the door link [1].
2) Remove the 2 screws [3].
F-3-140
3) Slide the upper cover [1] in the direction of the arrow.
4) Remove the 2 claws [2] of the upper cover, and detach the cover.
F-3-141
When mounting the upper cover, be sure to fit the 2 hooks [2] used to
release the fixing assembly in the 2 hook holes [1] found in the cover.
F-3-142
3.5.3.5 Removing the Rear Cover
0008-3609
1) Slide the rear cover [1] in the direction of the arrow to detach.
F-3-143
3.5.3.6 Removing the Power Supply PCB
0009-2770
1) Disconnect the flat cable [1].
2) Disconnect the 4 connectors [2], and free the harness [4] from the
harness guide [3].
F-3-144
3) Disconnect the high-voltage connector [1].
4) Remove the 6 screws [2], and detach the power supply PCB [3].
[1]
[3]
[
2]
[1]
[2]
[2]
Good positionBad position
[2]
[1]
[2]
[1]
[1]

Canon LBP2900 series Specifications

General

Print Technology	Laser
Print Speed	12 ppm (A4)
Paper Input Capacity	150 sheets
Connectivity	USB 2.0
Monthly Duty Cycle	Up to 2, 000 pages
Dimensions	370 x 251 x 217 mm
Weight	5.7 kg
Memory	2 MB
Supported Paper Sizes	A4, A5, B5, LGL, LTR, EXE, envelopes (COM10, Monarch, DL)
Operating System Compatibility	Windows, Mac OS, Linux
First Print Out Time	Approx. 9.3 seconds
