Canon MVX330i User Manual

34
Playing Back on a TV Screen
The AV terminal also serves as headphones terminal. When “ ” is displayed on the
screen, change the setting following the procedure below.
Open the menu and select [VCR SETUP]. Select [AV/PHONES ], set it to
[AV] and close the menu.
TVs with SCART Terminal
Refer also to the TV or VCR instruction manual.
1. Turn off all devices before starting the connections.
2. Connect the PC-A10 SCART Adapter to the TV or VCR’s terminals.
3. Connect the STV-250N Stereo Video Cable to the camcorder’s AV
terminal and the audio terminals on the SCART Adapter.
Connect the white plug to the white AUDIO terminal L (left), and the red plug to the red
AUDIO terminal R (right) and the yellow plug to the yellow VIDEO terminal.
4. If connecting to a TV, set the input selector to VIDEO. If connecting to
a VCR, set the input selector to LINE.
CAMERA
PLAY (VCR) CARD CAMERA CARD PLAY
MENU
(37)
VCR SETUP AV/PHONES •• AV
STV-250N Stereo Video
Cable (supplied)
Signal flow
PC-A10 SCART
Adapter

Canon MVX330i Specifications

General

Digital zoom	360 x
Optical zoom	18 x
Image stabilizer	Yes
Focal length range	45.4 - 817 mm
Sensor type	CCD
Total megapixels	1.33 MP
Optical sensor size	1/4.5 \
Display diagonal	2.5 \
Resolution	1280 x 960 pixels
Minimum illumination	0 lx

Weight and Dimensions

Depth	78 mm
Width	72 mm
Height	131 mm
Weight	500 g
