3-3
Basic Settings
Accessing the Settings Title Page
Note
This manual uses the IP address 192.168.100.1 (the factory default setting) below as
an example to describe the detail settings. Please enter the actual IP address that is
set in your VB-C50i/VB-C50iR.
The various settings on the VB-C50i/VB-C50iR are specified by using a browser to access Web
pages on the VB-C50i/VB-C50iR. To begin with, access the Settings Title Page.
1. Use the browser to access http://192.168.100.1/admin/.
Enter the IP address which you set up in “Perform Initial Settings for the Camera” (→ P.2-7).
Alternatively, access the top page of the camera server (→ P.2-10) and click the “Setting Page”.
2. Enter the user name and password.
In the factory default settings, the user name is
“root” and the password is “VB-C50i” (→ P.7-25).
* The password for both the VB-C50i and the VB-C50iR is
“VB-C50i”. Be sure to change the password on the System
and Network settings page (→ P.3-5).
The Setting Title Page appears.
Note
For security reasons, be sure to close the browser after you finish settings on the
settings page.
