4-21
VB Administration Tools
Preset Setting Tool
Setting Presets
You can set up Presets by either entering a value in the camera parameters or by using the
following 2 methods. Select the way which suits your environment or according to your preference.
Changing Settings from the Preset Preview Frame
The Preset Preview frame on the panorama picture can be used to set presets.
○○○○○○
To Make Settings...
1. From the Preset Selection box, select the
preset to be set and enter a name in “Preset
Name”.
2. Drag the Preset Preview frame shown on the
panorama picture to move or change its
shape and set the preset.
Alternatively, you can click at a spot on the picture to
make the center of the frame move to that point.
At this point, you can also enter and set values in the
camera parameters.
3. Click the “Apply” button.
Check the Status List to be sure the values were
applied correctly. Then when the “Save Settings” button
is clicked, the values will be saved to the VB-C50i/
VB-C50iR.
004-VBC50i-E-US 06.7.6, 11:35 AM21
