Canon XL H1 User Manual

148
1
Can be attached to the HD 20x L IS, 20x L IS, 16x IS II and 16x manual zoom lenses (only for recording in SD mode).
2
EF-S lenses cannot be used.
3
When you use the FU-1000 Monochrome CRT Viewfinder with the XL H1 you can use the compact power adapter or
the optional CB-920 Car Battery Adapter as the power source. You cannot use the battery adapter supplied with the
FU-1000; instead, connect the DC coupler directly to the XL H1 and connect it to the compact power adapter or the car
battery adapter.
Also, you cannot use the microphone protector supplied with the FU-1000 when using it with the XL H1.
4
When attaching EF lenses to the XL H1, the approximate 35 mm equivalent of the effective focal length is as follows: 4:3
- approx. 8.8x / 16:9 - approx. 7.2x.
5
Only when recording in SD 4:3 mode.

Canon XL H1 Specifications

General

Filter size	72 mm
Optical zoom	20 x
Image stabilizer	Yes
Focal length (35mm film equivalent)	38.9 - 778 mm
Sensor type	-
Total megapixels	1.67 MP
Effective megapixels (movie)	- MP
Focus	Auto/Manual
I/O ports	- IEEE1394 - EVF - SD in/out - S-Video - Headphone
Power consumption (typical)	7.8 W
Display diagonal	2.4 \
Maximum frame rate	25 fps
Camcorder tape type	Mini-DV
Compatible memory cards	MMC, SD
Firewire (IEEE 1394) ports	2
Product color	Black
Battery life (max)	5 h
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	496 mm
Width	226 mm
Height	220 mm
Weight	3750 g
