Canon XL H1 User Manual

77
E
Recording
Adjusting the Gain
The gain control adjusts the level of the video signal generated depending on the lighting and shooting
conditions. You can select from automatic gain control or preset levels that range from -3 to +18 dB.
1. Set the POWER dial to , Tv, Av or M.
2. Press the GAIN dial so that it pops out.
3. Turn the GAIN dial to adjust the level.
The selected level appears.
With some gain level settings the picture may flicker slightly.
-3 dB For the lowest noise recording for indoor, low light or low contrast scenes.
Auto Automatic adjustment of gain.
0 dB For lifelike night scenes or scenes under artificial lighting.
+3 dB/+6 dB/
+12 dB/+18 dB
Increases the brightness in indoor or low-light scenes. Increases the depth of field.
POWER dial
GAIN dial

Canon XL H1 Specifications

General

Filter size	72 mm
Optical zoom	20 x
Image stabilizer	Yes
Focal length (35mm film equivalent)	38.9 - 778 mm
Sensor type	-
Total megapixels	1.67 MP
Effective megapixels (movie)	- MP
Focus	Auto/Manual
I/O ports	- IEEE1394 - EVF - SD in/out - S-Video - Headphone
Power consumption (typical)	7.8 W
Display diagonal	2.4 \
Maximum frame rate	25 fps
Camcorder tape type	Mini-DV
Compatible memory cards	MMC, SD
Firewire (IEEE 1394) ports	2
Product color	Black
Battery life (max)	5 h
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	496 mm
Width	226 mm
Height	220 mm
Weight	3750 g
