Recording
Zoom Preset (Lenses equipped with the zoom preset function)
This function enables any given zoom setting to be memorized and to return to that zoom setting
instantly.
Presetting the Zoom
1. Set the POSITION PRESET switch to ZOOM.
2. Move the POSITION PRESET ON/SET switch to SET.
The preset zoom position appears in yellow on the zoom indicator.
Returning to the Preset Zoom Position
Move the POSITION PRESET ON/SET switch to ON.
The camcorder returns to the preset zoom position.
 The preset setting is canceled when you attach the optional Extender XL 1.6x or mount a lens with
a different magnification.
 The camcorder uses the zoom speed of the CONSTANT setting when returning to the preset zoom
position.
Changing the Zoom Bar Display
You can select to display the zoom position as a normal zoom bar or to display a numeric value instead.
Open the menu and select [DISPLAY SETUP/ ]. Select [ZOOM IND.], set it to [BAR] or
[NUMBER] and close the menu.
MENU
( 31)
DISPLAY SETUP / ZOOM IND. •••••• BAR
POSITION PRESET switch
POSITION PRESET ON/SET switch

Canon XL H1 Specifications

General

Filter size	72 mm
Optical zoom	20 x
Image stabilizer	Yes
Focal length (35mm film equivalent)	38.9 - 778 mm
Sensor type	-
Total megapixels	1.67 MP
Effective megapixels (movie)	- MP
Focus	Auto/Manual
I/O ports	- IEEE1394 - EVF - SD in/out - S-Video - Headphone
Power consumption (typical)	7.8 W
Display diagonal	2.4 \
Maximum frame rate	25 fps
Camcorder tape type	Mini-DV
Compatible memory cards	MMC, SD
Firewire (IEEE 1394) ports	2
Product color	Black
Battery life (max)	5 h
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	496 mm
Width	226 mm
Height	220 mm
Weight	3750 g
