110
E
Additional
Information
Specifications
ZR20
Power Supply (rated): 7.4 V DC
Power Consumption (while recording
with the AF turned on):
3.3 W (Using viewfinder),
4.2 W (Using LCD screen)
Television system:
EIA standard (525 lines, 60 fields) NTSC
color signal
Video recording system:
2 rotary heads, helical scanning
DV system (Consumer digital VCR SD
system)
Digital component recording
Audio recording system:
PCM digital sound: 16 bit (48kHz/2ch),
12 bit (32kHz/4ch)
Image sensor: 1/4” CCD (charge coupled
device), approx. 460,000 pixels (approx.
290,000 effective pixels)
Tape format: Videocassettes bearing the
D mark.
Tape speed:
SP:
3
/4 ips (18.81 mm/s),
LP:
1
/2 ips (12.56 mm/s)
Maximum recording time (with an 80
min. cassette):
SP: 80 min., LP: 120 min.
Fast forward/rewind time:
Approx. 2 min. 20 sec. (with a
60 min. cassette)
Lens: F/1.8–2.9, 10× power zoom,
4.2–42.0 mm
Focusing system: TTL autofocus, manual
focusing possible
Minimum focusing distance: 3ft 3
3
/8
in
(1 m) (
3
/8 in (1 cm) on maximum wide
angle)
Maximum shutter speed:
1/8,000 sec.
Minimum illumination: 2.5 lx (using the
Low Light program)
Recommended illumination:
More than 100 lx
Filter diameter: 30.5 mm
Viewfinder: 0.44 in, TFT color LCD,
approx. 113,000 pixels
LCD screen: 2.5 in measured diagonally,
TFT color, approx. 112,000 pixels
Microphone: Stereo electret condenser
microphone
DV terminal input/output:
Special 4-pin connector (conforms to
IEEE1394)
AV/headphone terminal:
ø 3.5 mm minijack
Audio input: –10dBV/ at least 40 kohms,
(L, R), unbalanced
output: –10dBV (47 kohm load)/
less than 3 kohms,
unbalanced
Video: 1 Vp-p/75 ohms unbalanced
S-video terminal input/output:
1 Vp-p (Y signal), 0.286 Vp-p (C signal)
MIC terminal input: ø 3.5 mm stereo
minijack, – 57 dBV (with 600 ohm mic)/
at least 5 kohms
LANC
u
terminal: ø 2.5 mm mini
minijack
Operating temperature range: 32–104 °F
(0–40 °C)
Dimensions: 2
1
/4 × 4 × 5
1
/4 in
(57 × 102 × 134 mm)
Weight: 1 lb 3 oz (540 g)
Battery type: Rechargeable lithium ion
battery
Rated voltage: 7.4 V DC
Operating temperature: 32°–104°F
(0°–40°C)
Battery capacity: 1100 mAh
Dimensions: 1
1
/2 ×
7
/8 × 2
1
/8 in
(38 × 21 × 55 mm)
Weight: 2
1
/2 oz (70 g)
Weight and dimensions are approximate
Errors and omissions excepted.
Subject to change without notice.
Canon is a trademark of Canon Inc.
BP-512 Battery Pack
