5.6 Table of easy parameters
Par. Description Type Min Max UOM. Def. Parameter visible in models
PS password F 0 200 - 22 M/S (with 1 & 2 probes), X, Y, C
/2 probe measurement stability C 1 15 - 4 M/S (with 1 & 2 probes), X, Y, C
/4 select probe displayed F 1 3 - 1 M/ S (with 2 probes), X, Y, C
/5 select °C/°F C 0(°C) 1(°F) - 0 M/ S (with 1 & 2 probes), X, Y, C
/6 disable decimal point C 0 1 - 0 M/S (with 1 & 2 probes), X, Y, C
/7 enable probe 2 alarm (model M only) C 0 1 - 0 M
/C1 probe 1 o set F -50.0 50.0 (°C/°F) 0 M/S (with 1 & 2 probes), X, Y, C
/C2 probe 2 o set F -50.0 50.0 (°C/°F 0 M/S (with 2 probes), X, Y, C
/C3 probe 3 o set F -50.0 50.0 (°C/°F) 0 M/S (with 2 probes), X, Y, C
St set point S r1 r2 °C/°F 4 M/S (with 1 & 2 probes), X, Y, C
rd control di erential F 0 19.0 °C/°F 2 S (with 1 & 2 probes), X, Y, C
r1 maximum set point value C -50 r2 °C/°F -50 M/S (with 1 & 2 probes), X, Y, C
r2 select direct/reverse operation C r1 200 °C/°F 90 S (with 1 & 2 probes), X, Y, C
r3 night-time set point delta C 0 2 - 0 M/S (with 2 probes), X, Y, C
r4 control di erential C -50 50 °C/°F 3 S (with 1 & 2 probes), X, Y, C
c0 compressor and fan start delay on power-up C 0 100 min 0 S (with 1 & 2 probes), X, Y, C
c1 minimum time between consecutive compressor starts C 0 100 min 0 S (with 1 & 2 probes), X, Y, C
c2 minimum compressor o time C 0 100 min 0 S (with 1 & 2 probes), X, Y, C
c3 minimum compressor on time C 0 100 min 0 S (with 1 & 2 probes), X, Y, C
c4 compressor on time with duty setting C 0 100 min 0 S (with 1 & 2 probes), X, Y, C
cc continuous cycle duration C 0 15 h 4 S (with 1 & 2 probes), X, Y, C
c6 temperature alarm bypass after continuous cycle C 0 15 h 2 S (with 1 & 2 probes), X, Y, C
d0 type of defrost C 0 4 - 0 S (with 1 & 2 probes), X, Y, C
dI interval between defrosts F 0 199 h/min (see dC) 8 S (with 1 & 2 probes), X,Y, C
dt end defrost temperature set point/defrost temperature
threshold with temp. control
F -50 130 °C/°F 4 S (with 2 probes), X, Y, C
dP maximum defrost duration F 1 199 min/s (see dC) 30 S (with 1 & 2 probes), X, Y, C
d4 defrost when switching the instrument on C 0 1 - 0 S (with 1 & 2 probes), X, Y, C
d5 defrost delay on power-up or when enabled by digital input C 0 199 min 0 S (with 1 & 2 probes), X, Y, C
d6 freeze control temperature display during defrost C 0 1 - 1 S (with 1 & 2 probes), X, Y, C
dd dripping time F 0 15 min 2 S (with 1 & 2 probes), X, Y, C
d8 alarm bypass time after defrost F 0 15 h 1 S (with 1 & 2 probes), X, Y, C
d9 defrost priority over compressor protectors C 0 1 - 0 S (with 1 & 2 probes), X, Y, C
d/ defrost probe reading (2) F - - °C/°F - S (with 2 probes), X, Y, C,
dC time base C 0 1 - 0 S (with 1 & 2 probes), X, Y, C
A0 alarm and fan temperature di erential C -20 20.0 °C/°F 2 M/S (with 1 & 2 probes), X, Y, C
AL absolute/relative temperature for low temperature alarm F -50 250 °C/°F 0 M/S (with 1 & 2 probes), X, Y, C
AH absolute/relative temperature for high temperature alarm F -50 250 °C/°F 0 M/S (with 1 & 2 probes), X, Y, C
Ad temperature alarm delay C 0 199 min 0 M/S (with 1 & 2 probes), X, Y, C
A4 3rd input con guration C 0 11 - 0 M/S (with 2 probes), X, Y, C
A7 digital input alarm delay C 0 199 min 0 M/S (with 2 probes), X, Y, C
A8 enable alarm “Ed” (end defrost by timeout) C 0 1 - 0 S (with 2 probes), X, Y, C
Ac set point dirty condenser alarm C -50 250 °C/°F 70 M/S (with 2 probes), X, Y, C
AE dirty condenser alarm di erential temperature C 0.1 20.0 °C/°F 5.0 M/S (with 2 probes),X, Y, C
Acd dirty condenser alarm delay C 0 250 min 0 M/S (with 2 probes), X, Y, C
F0 enable evaporator fan control C 0 1 - 0 C
F1 evaporator fan control set point F -50 130 °C/°F +5 C
F2 stop evaporator fan if compressor o C0 1 - 1C
F3 evaporator fan status during defrost C 0 1 - 1 C
Fd post-dripping time F 0 15 min 1 C
H0 serial address C 0 207 - 1 M/S (with 1 & 2 probes), X, Y, C
H1 AUX output con guration C 0 3 - 0 M/S (with 1 & 2 probes), X, Y, C
H2 enable keypad C 0 1 - 1 M/S (with 1 & 2 probes), X, Y, C
H4 disable buzzer C 0 1 - 0 M/S (with 1 & 2 probes), X, Y, C
H5 ID code (read-only) F 0 199 - - M/S (with 1 & 2 probes), X, Y, C
EZY rapid parameter set selection C 0 4 - 0 S (with 1 & 2 probes), X, Y, C
tEn enable RTC C 0 1 - 0 X, Y, C (*)
d1d defrost time band 1st day C 0 11 days 0 X, Y, C (*)
d1h time band 1st hour C 0 23 h 0 X, Y, C (*)
d1M time band 1st minute C 0 59 min 0 X, Y, C (*)
d2d defrost time band 2nd day C 0 11 days 0 X, Y, C (*)
d2h time band 2nd hour C 0 23 h 0 X, Y, C (*)
d2M time band 2nd minute C 0 59 min 0 X, Y, C (*)
d3d defrost time band 3rd day C 0 11 days 0 X, Y, C (*)
d3h time band 3rd hour C 0 23 h 0 X, Y, C (*)
d3M time band 3rd minute C 0 59 min 0 X, Y, C (*)
d4d defrost time band 4th day C 0 11 days 0 X, Y, C (*)
d4h time band 4th hour C 0 23 h 0 X, Y, C (*)
d4M time band 4th minute C 0 59 min 0 X, Y, C (*)
nOd night time band ON day C 0 11 days 0 X, Y, C (*)
nOh night time band ON hours C 0 23 h 0 X, Y, C (*)
nOM night time band ON minutes C 0 59 min 0 X, Y, C (*)
nFd night time band OFF day C 0 11 days 0 X, Y, C (*)
nFh night time band OFF hours C 0 23 h 0 X, Y, C (*)
nFM night time band OFF minutes C 0 59 min 0 X, Y, C (*)
AOd AUX time band ON day C 0 11 days 0 X, Y, C (*)
AOh AUX time band ON hours C 0 23 h 0 X, Y, C (*)
AOM AUX time band ON minutes C 0 59 min 0 X, Y, C (*)
