START-UP Alternate Wire Lugs
If the incoming power wire size does not fit the standard lug, alter-
nate lugs may be used. See Table 1. Note that lugs rated for a high-
er current than the circuit breaker may be used.
Verify Installation
Record the following job information:
1. Job Name
2. Job Number
3. City
4. State
5. Zip Code
Record the following nameplate information:
1. From the Allen-Bradley nameplate (Fig. 1) located inside
the VFD enclosure:
a. Allen-Bradley ID or CAT NO.
b. Allen-Bradley Serial Number
c. Carrier Part Number
2. From the machine nameplate (Fig. 10) located inside the
VFD enclosure:
a. Chiller Serial Number
b. Chiller Model
c. Motor rated load amps
d. Motor nameplate rpm
e. Motor nameplate kW
f. Motor nameplate voltage
g. Inverter PWM (pulse width modulation) frequency
h. Voltage
3. From the drive module label (Fig. 11) located on the drive
module:
a. Model or Cat. Number
b. Serial Number
4. From the HMI control panel screen:
a. Carrier Part Number and Revision
b. Software Number
Table 1 — Wire Lugs
DANGER
Internal components and circuit boards of the drive are live
when the drive is connected to incoming power. Coming into
contact with this voltage is extremely dangerous and will result
in severe personal injury or death.
The motor terminals U, V, W and the DC-link/brake resistor
terminals B+/R+, R- are live when the drive is connected to in-
coming power, even if the motor is not running.
Do not make any connections when the drive is connected to
the incoming power.
After having disconnected the drive, wait until the indicators
on the keypad go out (if no keypad is attached see the indicator
through the keypad base). Wait 5 more minutes before doing
any work on drive connections. Do not even open the cover
before this time has expired.
Before connecting the drive to the incoming power, make sure
that the switchgear enclosure door is closed.
WARNING
The control I/O-terminals are isolated from the mains poten-
tial. However, the relay outputs and other I/O terminals may
have a dangerous control voltage present even when the drive
is disconnected from incoming power. Coming into contact
with this voltage could result in severe personal injury.
CAUTION
If other than refrigerant cooling is used, before connecting the
drive to the incoming power, make sure that the coolant is cir-
culating and has no leaks.
CAUTION
When working with the Drive Explorer, never use the Rotate
function as the motor will immediately start and severe com-
pressor damage could result.
VOLTAGE
CARRIER VFD MAX
INPUT AMPS
STANDARD
ABB LUG
STANDARD LUG
CABLE RANGE
ALTERNATE
ABB LUG
ALTERNATE LUG
CABLE RANGE
480
230 KT5300 (1) 250 - 500 MCM KT5400 (2) 3/0 - 250 MCM
335 K6TJ (3) 2/0 - 400 MCM K6TH (2) 250 - 500 MCM
445 K6TJ (3) 2/0 - 400 MCM K6TH (2) 250 - 500 MCM
380/400/415
230 KT5400 (2) 3/0 - 250 MCM KT5300 (1) 250 - 500 MCM
335 K6TJ (3) 2/0 - 400 MCM K6TH (2) 250 - 500 MCM
445 K6TJ (3) 2/0 - 400 MCM K6TH (2) 250 - 500 MCM
600 269 KT5300 (1) 250 - 500 MCM KT5400 (2) 3/0 - 250 MCM
