Casio CASSIOPEIA A-20 User Manual

— 67 —
Item Code No. Parts Name Specifications Q R
DP UPPER CASE UNIT
50 6670 1921 TOUCH PANEL ASS'Y C341909*1 1 A
51 6670 1919 PCB ASS'Y/MIC C241138*1 1 C
52 6562 1440 RUBBER/STOPPER C442144-1 2 C
53 6566 0180 CASE/UPPER (DISPLAY) C140651-1 1 C
54 6566 0200 BUTTON/NOTIFICATION (LED) C341825-1 1 X
55 6566 0210 SHAFT PIECE C341824-1 1 X
56 6339 1750 SCREW A33953-33 8 X
57 3335 6654 UNIT/LCD MD554TN00-E2 1 A
58 6670 1920 MIC ASS'Y C442406*2 1 B
59 6566 0240 HOLDER/MIC C442524-1 1 C
60 6670 1918 PCB ASS'Y/LED C341912*1 1 B
61 6562 1170 SCREW C442157-1 1 X
Z370-1 UNIT
X1 2254 0540 OSCILLATOR/CERAMIC CSTCC3.68MG-TC 1 C
X2 2254 0539 OSCILLATOR/CERAMIC CSTCC10.0MG-TC 1 C
X3 2590 2740 OSCILLATOR/CRYSTAL C-004R-12P15-20 1 B
CN7 2254 0558 CONNECTOR WR-80P-VF50-1-E13 1 C
CN2 2254 0533 CONNECTOR 145027068140833 1 C
CN101 2254 0553 CONNECTOR HEC3650-012010 1 B
CN6 2254 0554 CONNECTOR 53927-5018 1 C
CN4 3013 2586 CONNECTOR 3560-16SR1(11) 1 B
CN8,CN200 2254 0537 CONNECTOR IL-FPR-30S-VF-E 2 B
CN9,CN100 7930 0471 CONNECTOR 24 8005 002 000867 2 B
CN5 3501 8197 JACK HSJ1169-019010 1 C
SW1,SW101 2254 0557 SWITCH ESE11MH2T 2 B
SW100 2254 0532 SWITCH ESE22MH2 1 B
F100,F101 3632 0714 FUSE/CHIP F0805B3R00FW 2 B
IC4 2254 0527 IRDA MODULE CIM-10S 1 B
IC105,IC106 2105 6223 CONVERTER /DC-DC MAX608ESA-T 2 C
IC111 2775 3312 CONVERTER/DC-DC MAX1651CSA-T 1 C
IC9 2116 0225 IC/AMP MC34119DTBEL 1 C
RAM5,RAM6 2012 5794 LSI/RAM HM51W16165LTBV-7 2 C
RAM7,RAM8 2012 5795 LSI/RAM HM51W16165LTBE-7 2 C
ACCESSORY
3301 0448 AC ADAPTOR AD-C50200U 1 X
3335 6594 CABLE/RS232C TPX1375-010100 1 X
3335 6657 SOFTWARE/CD-ROM (MS) CDZ340AA01A 1 X
3335 6658 SOFTWARE/CD-ROM (CASIO) CDZ340AA02A 1 X
Notes: Q
– Quantity used per unit A: Essential
R – Rank B: Stock recommended
C: Others
D: No stock recommend
R –
