PARTS LIST
Item Code No. Parts Name Specifications Q R
COMPONENT
1 6670 1912 CASE/LOWER (DISPLAY) C341910*1 1 C
2 6562 1170 SCREW C442157-1 6 X
3 6566 0220 COVER/LED C341823-1 1 X
4 6670 1908 CASE ASS'Y/BATTERY (MAIN) C140597*2 1 B
5 6339 1750 SCREW A33953-33 5 X
6 6566 0280 PLATE/RATING C241038-5 1 X
7 6562 1140 COVER/CONNECTOR C341538-1 1 B
8 6562 1730 PEN ASS'Y C341657*1 1 A
9 6670 2075 CARD ASS'Y/DUMMY C241046*2 1 X
10 6670 1909 PCB ASS'Y/ROM C140601*2 1 B
11 6566 0270 LABEL/BATTERY (BACK-UP) C341668-2 1 X
12 6390 0432 CAP A310765B-1 1 B
KEY LOWER CASE ASSY
13 6418 4250 SPRING C441562-1 1 C
14 6562 1260 LEVER/BATTERY C241000-1 1 C
15 6562 1270 HOLDER/PEN C241001-1 1 X
16 6562 1280 FILTER C341539-1 1 B
17 6562 1390 SCREW C341659-1 3 X
18 6562 2580 SPACER C442378-1 1 X
19 6670 1650 PCB ASS'Y/BATTERY (BATTERY) C341683*1 1 C
20 6562 1740 CASE/LOWER (KEYBOARD) C140544-1 1 C
21 6562 1670 COVER/BATTERY (BACK-UP) C341535-1 1 B
22 6562 1660 COVER/ROM C341536-1 1 X
23 6562 1650 COVER/CF CARD C341537-1 1 B
KEY UPPER CASE UNIT
24 6562 1310 HOLDER/HINGE C341542-1 1 X
25 6339 1750 SCREW A33953-33 4 X
26 3335 6652 UNIT/TILT ST145A0001 1 C
27 6339 1750 SCREW A33953-33 4 X
28 6562 1370 HOLDER/TERMINAL (LEFT) C341540-1 1 X
29 6562 1380 HOLDER/TERMINAL (RIGHT) C341541-1 1 X
30 6562 1390 SCREW C341659-1 12 X
31 6562 1400 BLACKET/SPEAKER C442147-1 1 X
32 6562 1410 NET/SPEAKER C442148-1 1 X
33 6562 1890 SPRING/EARTH C442306-1 1 X
34 6562 2550 SPACER/KEY C442419-1 1 C
35 6566 0250 FILM/KEYBOARD C140548-2 1 C
36 6566 0260 KEYBOARD C140549-2 1 C
37 6566 0390 CASE/UPPER (KEYBOARD) C140547-2 1 C
38 6670 1915 PCB ASS'Y/CPU C140598*3 1 A
39 6670 1654 SPEAKER ASS'Y C341682*1 1 B
40 6562 1470 SHIELD/PC CARD C241002-1 1 X
41 6562 1480 SHIELD/CF CARD C341559-1 1 X
42 6562 1490 BLIND C442158-1 1 X
43 6562 1510 FRAME/CONNECTOR 305027000952000 1 C
44 6562 1520 FRAME/CONNECTOR 55021-0001 1 C
45 6670 1658 TERMINAL ASS'Y/CHGOUT (CN104) C341715*1 1 C
46 6670 1659 TERMINAL ASS'Y/DETFULL (CN105) C341716*1 1 C
47 6670 1660 TERMINAL ASS'Y/POSITIVE POLE (CN103) C341717*1 1 C
48 6670 1661 TERMINAL ASS'Y/NEGATIVE POLE (CN106) C341718*1 1 C
49 6511 4660 SCREW A310044-25 1 X
Notes: Q
– Quantity used per unit A: Essential
R – Rank B: Stock recommended
C: Others
D: No stock recommend
