141
Using the Camera with a Computer
. Computer System Requirements for Software
Computer system requirements are different for each of the applications. Information
about computer system requirements can be found under “Computer System
Requirements for Software (For Windows)” on page 178 of this manual.
. Precautions for Windows Users
The software requires Administrator privileges to run.
Operation on a self-made computer is not supported.
Operation may not be possible under certain computer environments.
You can connect the camera to your computer in order to view and store images
(snapshot and movie files).
IMPORTANT!
Never unplug the USB cable, or operate the camera while viewing or storing
images. Doing so can cause data to become corrupted.
NOTE
You also can use your computer’s card slot (if it has one) or a commercially
available card reader to access image files directly from the camera’s memory
card. For details, see the user documentation that comes with your computer.
. To connect the camera to your computer and save files
1. Turn on the camera and press [MENU].
2. On the “Set Up” tab, select “USB” and then press [6].
3. Use [8] and [2] to select “Mass Storage”, and then press [SET].
Viewing and Storing Images on a Computer
Never use your computer to modify, delete, move, or rename any image files
that are in the camera’s built-in memory or on its memory card.
Doing so can cause problems with the camera’s image management data, which
will make it impossible to play back images on the camera and can drastically alter
remaining memory capacity. Whenever you want to modify, delete, move, or
rename an image, do so only on images that are stored on your computer.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Casio EXILIM EX-ZR300 and is the answer not in the manual?

Casio EXILIM EX-ZR300 Specifications

General IconGeneral
Megapixel16.1 MP
Camera typeCompact camera
Sensor typeCMOS
Image stabilizerNo
Total megapixels16.79 MP
Image sensor size1/2.3 \
Supported aspect ratios3:2, 16:9
Maximum image resolution4608 x 3456 pixels
Still image resolution(s)640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072
Digital zoom4 x
Optical zoom12.5 x
Combined zoom199.3 x
Focal length range4.24 - 53 mm
Maximum aperture number7.9
Minimum aperture number3
Lens structure (elements/groups)8/9
Maximum focal length (35mm film equiv)300 mm
Minimum focal length (35mm film equiv)24 mm
Normal focusing range0.05 - ∞ m
Auto focusing (AF) modesMulti Point Auto Focus, Spot Auto Focus, Tracking Auto Focus
Macro focusing range (wide)0.01 - 0.5 m
Light meteringCentre-weighted, Evaluative (Multi-pattern)
ISO sensitivity80, 100, 200, 400, 800, 1600, 3200
Light exposure modesAperture priority AE, Manual, Shutter priority AE
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed4 s
Flash modesAuto, Red-eye reduction
Flash range (tele)0.9 - 2.4 m
Flash range (wide)0.4 - 4.7 m
Flash recharging time5 s
Built-in flashYes
Power source typeAC
Dimensions (WxDxH)104.8 x 28.6 x 59.1 mm
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedAVCHD, H.264, MOV
Maximum video resolution1920 x 1080 pixels
Internal memory52.2 MB
Compatible memory cardsSD, SDHC, SDXC
Maximum memory card size16 GB
Display diagonal3 \
Display resolution960 x 480 pixels
Display resolution (numeric)460800 pixels
USB version2.0
Product colorWhite
Scene modes-
White balanceAuto, Daylight, Manual, Shade
Camera playbackMovie
Self-timer delay2, 10 s
Camera file systemDCF 2.0, DPOF 1.1, Exif 2.3
Battery typeNP-130
Battery life (CIPA standard)500 shots
Cables includedUSB
Weight and Dimensions IconWeight and Dimensions
Depth28.6 mm
Width104.8 mm
Height59.1 mm
Weight165 g
Weight (including battery)205 g
