Casio EXILIM EX-ZR300 User Manual

188
Appendix
Display Messages
ALERT
The camera’s protection function may have activated
because camera temperature is too high. Turn off the
camera and wait until it cools down before trying to use it
again.
Battery is low. Battery power is low.
Cannot find the file.
The image you specified with the slideshow “Images”
setting cannot be found. Change the “Images” setting (page
116) and try again.
Cannot register any
more files.
You are attempting to save a user BEST SHOT scene in
the “SCENE” folder when the folder already contains 999
user scenes.
Card ERROR
There is something wrong with the memory card. Turn off
the camera, remove the memory card and then reload it
into the camera. If this message re-appears when you turn
the camera back on, format the memory card (page 167).
IMPORTANT!
• Formatting a memory card deletes all its files. Before
formatting, try transferring recoverable files to a
computer or some other storage device.
Check connections!
You are attempting to connect the camera to a printer while
the camera’s USB settings are not compatible with the USB
system of the printer (page 132).
Connecting to the
network
Camera power was turned off while image data was being
copied to a computer or other device using a FlashAir card
or an Eye-Fi card (pages 152, 153).
Files could not be
saved because
battery is low.
Battery power is low, so an image file could not be saved.
Folder cannot be
created.
You are trying to record a file while there are already 9999
files stored in the 999th folder. If you want to record more,
delete files you no longer need (page 34).
LENS ERROR
This message appears and the camera turns off whenever
the lens performs some unexpected operation. If the same
message appears after you turn power back on, contact a
CASIO authorized service center or your original retailer.
LENS ERROR 2
The Anti Shake unit of the camera may be malfunctioning.
If the same message appears after you turn power back on,
contact your retailer or a CASIO authorized service center.
Load paper! The printer ran out of paper while printing.

Casio EXILIM EX-ZR300 Specifications

General

Megapixel	16.1 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	No
Total megapixels	16.79 MP
Image sensor size	1/2.3 \
Supported aspect ratios	3:2, 16:9
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072
Digital zoom	4 x
Optical zoom	12.5 x
Combined zoom	199.3 x
Focal length range	4.24 - 53 mm
Maximum aperture number	7.9
Minimum aperture number	3
Lens structure (elements/groups)	8/9
Maximum focal length (35mm film equiv)	300 mm
Minimum focal length (35mm film equiv)	24 mm
Normal focusing range	0.05 - ∞ m
Auto focusing (AF) modes	Multi Point Auto Focus, Spot Auto Focus, Tracking Auto Focus
Macro focusing range (wide)	0.01 - 0.5 m
Light metering	Centre-weighted, Evaluative (Multi-pattern)
ISO sensitivity	80, 100, 200, 400, 800, 1600, 3200
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	4 s
Flash modes	Auto, Red-eye reduction
Flash range (tele)	0.9 - 2.4 m
Flash range (wide)	0.4 - 4.7 m
Flash recharging time	5 s
Built-in flash	Yes
Power source type	AC
Dimensions (WxDxH)	104.8 x 28.6 x 59.1 mm
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVCHD, H.264, MOV
Maximum video resolution	1920 x 1080 pixels
Internal memory	52.2 MB
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	16 GB
Display diagonal	3 \
Display resolution	960 x 480 pixels
Display resolution (numeric)	460800 pixels
USB version	2.0
Product color	White
Scene modes	-
White balance	Auto, Daylight, Manual, Shade
Camera playback	Movie
Self-timer delay	2, 10 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3
Battery type	NP-130
Battery life (CIPA standard)	500 shots
Cables included	USB

Weight and Dimensions

Depth	28.6 mm
Width	104.8 mm
Height	59.1 mm
Weight	165 g
Weight (including battery)	205 g
