Casio EXILIM EX-ZR300 User Manual

152
Using the Camera with a Computer
Shooting with an Eye-Fi wireless SD memory card loaded in the camera makes it
possible to transfer image data automatically to a computer via wireless LAN.
1. Configure LAN access point, transfer destination and other settings for
the Eye-Fi card in accordance with the instructions that come with the
Eye-Fi card.
2. After configuring settings, load the Eye-Fi card into the camera and
record.
Images you record are sent by wireless LAN to your computer, etc.
• For full details, see the user documentation that comes with the Eye-Fi card.
• Before formatting a new Eye-Fi card to use it for the first time, copy the Eye-Fi
Manager install files to your computer. Do this before formatting the card.
IMPORTANT!
• Recorded images are transferred over wireless LAN. Do not use the Eye-Fi card or
turn off Eye-Fi card communication (page 159) when on an aircraft or in any other
location where use of wireless communication is limited or prohibited.
• Loading an Eye-Fi card will cause the Eye-Fi indicator to
appear on the monitor screen. Its transparent or not transparent
appearance indicates the communication status as shown below.
• A communication icon will appear on the monitor screen while image data
transfer is in progress.
• The camera’s Auto Power Off (page 164) function is disabled while image data
transfer is in progress.
• A confirmation message will appear on the monitor screen if you try to turn off the
camera while image data transfer is in progress. Follow the instructions in the
messages (page 188).
• Transfer of a large number of images can take some time to complete.
• Depending on the type of Eye-Fi card you are using and its settings, images on the
Eye-Fi card may be deleted following image data transfer.
• Breaks in the image and/or audio may occur when recording a movie to or playing
a movie from an Eye-Fi card.
• Proper Eye-Fi card data communication may not be possible due to camera
settings, battery level, or operating conditions.
Using an SD Memory Card with Built-in LAN
Transferring Images with an Eye-Fi Card (Eye-Fi)
Transparent
Access point cannot be found or no
transferable image data exists.
Not transparent Image transfer in progress
Flashing Searching for access points

Casio EXILIM EX-ZR300 Specifications

General

Megapixel	16.1 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	No
Total megapixels	16.79 MP
Image sensor size	1/2.3 \
Supported aspect ratios	3:2, 16:9
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072
Digital zoom	4 x
Optical zoom	12.5 x
Combined zoom	199.3 x
Focal length range	4.24 - 53 mm
Maximum aperture number	7.9
Minimum aperture number	3
Lens structure (elements/groups)	8/9
Maximum focal length (35mm film equiv)	300 mm
Minimum focal length (35mm film equiv)	24 mm
Normal focusing range	0.05 - ∞ m
Auto focusing (AF) modes	Multi Point Auto Focus, Spot Auto Focus, Tracking Auto Focus
Macro focusing range (wide)	0.01 - 0.5 m
Light metering	Centre-weighted, Evaluative (Multi-pattern)
ISO sensitivity	80, 100, 200, 400, 800, 1600, 3200
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	4 s
Flash modes	Auto, Red-eye reduction
Flash range (tele)	0.9 - 2.4 m
Flash range (wide)	0.4 - 4.7 m
Flash recharging time	5 s
Built-in flash	Yes
Power source type	AC
Dimensions (WxDxH)	104.8 x 28.6 x 59.1 mm
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVCHD, H.264, MOV
Maximum video resolution	1920 x 1080 pixels
Internal memory	52.2 MB
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	16 GB
Display diagonal	3 \
Display resolution	960 x 480 pixels
Display resolution (numeric)	460800 pixels
USB version	2.0
Product color	White
Scene modes	-
White balance	Auto, Daylight, Manual, Shade
Camera playback	Movie
Self-timer delay	2, 10 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3
Battery type	NP-130
Battery life (CIPA standard)	500 shots
Cables included	USB

Weight and Dimensions

Depth	28.6 mm
Width	104.8 mm
Height	59.1 mm
Weight	165 g
Weight (including battery)	205 g
