Casio EXILIM EX-ZR300 User Manual

175
Appendix
Any and all unauthorized copying, distribution, and transfer for commercial purposes
of the software provided by CASIO for this product are prohibited.
This product’s YouTube upload functionality is included under license from YouTube,
LLC. The presence of YouTube upload functionality in this product is not an
endorsement or recommendation of the product by YouTube, LLC.
. If the camera’s back lamp starts flashing red...
If the back lamp starts flashing red during charging, it means that further charging is
not possible for one of the reasons below. Perform the actions described below to
correct the problem and then try charging again.
Ambient temperature or the temperature of the battery is abnormally high
or low
Unplug the USB cable from the camera and wait for a while until the camera is within
the temperature range of 10°C to 35°C (50°F to 95°F), and then try charging again.
Safety timer activated
A battery that has not been used for a long time, certain types of computers, and
connection conditions can cause charging to take longer than normal. If charging
takes longer than about six hours, a safety timer will terminate it automatically, even if
the battery is not fully charged. If the battery has not been used for a very long time,
charging may terminate automatically after only about 45 minutes.
1) Using a battery that has not been used for a long time.
Disconnect and then reconnect the USB cable to resume charging.
2) Insufficient power supply when connected to computer
Connect directly to a USB port what supplies a current of 500mA.
For details about the power supply capacity of a computer’s USB port, contact the
manufacturer of the computer. Though disconnecting and then reconnecting the USB
cable will resume charging, you may need to do so repeatedly if the power supply
capacity of the computer is low.
Power Supply
Charging
If problems continue to occur after you perform the above steps, it could mean that
the battery is faulty. Contact your nearest CASIO authorized service center.

Casio EXILIM EX-ZR300 Specifications

General

Megapixel	16.1 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	No
Total megapixels	16.79 MP
Image sensor size	1/2.3 \
Supported aspect ratios	3:2, 16:9
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072
Digital zoom	4 x
Optical zoom	12.5 x
Combined zoom	199.3 x
Focal length range	4.24 - 53 mm
Maximum aperture number	7.9
Minimum aperture number	3
Lens structure (elements/groups)	8/9
Maximum focal length (35mm film equiv)	300 mm
Minimum focal length (35mm film equiv)	24 mm
Normal focusing range	0.05 - ∞ m
Auto focusing (AF) modes	Multi Point Auto Focus, Spot Auto Focus, Tracking Auto Focus
Macro focusing range (wide)	0.01 - 0.5 m
Light metering	Centre-weighted, Evaluative (Multi-pattern)
ISO sensitivity	80, 100, 200, 400, 800, 1600, 3200
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	4 s
Flash modes	Auto, Red-eye reduction
Flash range (tele)	0.9 - 2.4 m
Flash range (wide)	0.4 - 4.7 m
Flash recharging time	5 s
Built-in flash	Yes
Power source type	AC
Dimensions (WxDxH)	104.8 x 28.6 x 59.1 mm
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVCHD, H.264, MOV
Maximum video resolution	1920 x 1080 pixels
Internal memory	52.2 MB
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	16 GB
Display diagonal	3 \
Display resolution	960 x 480 pixels
Display resolution (numeric)	460800 pixels
USB version	2.0
Product color	White
Scene modes	-
White balance	Auto, Daylight, Manual, Shade
Camera playback	Movie
Self-timer delay	2, 10 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3
Battery type	NP-130
Battery life (CIPA standard)	500 shots
Cables included	USB

Weight and Dimensions

Depth	28.6 mm
Width	104.8 mm
Height	59.1 mm
Weight	165 g
Weight (including battery)	205 g
