Casio EXILIM EX-ZR300 User Manual

83
Using BEST SHOT
With this feature, a number of images are shot and then combined to produce an
image with a super-wide angle of view that exceeds the widest angle of view possible
with the lens. Converted to 35 mm equivalents, the focal distances available with this
feature enable shooting with approximate angles of view of 14 mm and 18 mm.
1. In the REC mode, set the mode dial to [b] (BEST SHOT).
2. Press [SET].
3. Select “Wide Shot” and then press [SET].
4. Press [2] and then use [8] and [2] to select the width setting, which
is the second Control Panel setting from the top.
5. Use [4] and [6] to select the width setting (angle of view) you want and
then press [SET].
There are two settings available: “Wide 1 (18 mm)” and “Wide 2 (14 mm)”.
“14 mm” shoots a wider area than “18 mm”.
6. Hold the camera so it is
upright, with the shutter
button and other controls
at the bottom.
• Do not point the camera
straight down at the ground
at this time. If you do, the
camera’s built-in vertical/
horizontal position sensor
will not operate properly
and may make it impossible
to start shooting.
Shooting with a Super Wide Angle of View (Wide Shot)
24 mm (lens widest angle) Wide 1 (18 mm) Wide 2 (14 mm)
Shutter button
Control button

Casio EXILIM EX-ZR300 Specifications

General

Megapixel	16.1 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	No
Total megapixels	16.79 MP
Image sensor size	1/2.3 \
Supported aspect ratios	3:2, 16:9
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072
Digital zoom	4 x
Optical zoom	12.5 x
Combined zoom	199.3 x
Focal length range	4.24 - 53 mm
Maximum aperture number	7.9
Minimum aperture number	3
Lens structure (elements/groups)	8/9
Maximum focal length (35mm film equiv)	300 mm
Minimum focal length (35mm film equiv)	24 mm
Normal focusing range	0.05 - ∞ m
Auto focusing (AF) modes	Multi Point Auto Focus, Spot Auto Focus, Tracking Auto Focus
Macro focusing range (wide)	0.01 - 0.5 m
Light metering	Centre-weighted, Evaluative (Multi-pattern)
ISO sensitivity	80, 100, 200, 400, 800, 1600, 3200
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	4 s
Flash modes	Auto, Red-eye reduction
Flash range (tele)	0.9 - 2.4 m
Flash range (wide)	0.4 - 4.7 m
Flash recharging time	5 s
Built-in flash	Yes
Power source type	AC
Dimensions (WxDxH)	104.8 x 28.6 x 59.1 mm
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVCHD, H.264, MOV
Maximum video resolution	1920 x 1080 pixels
Internal memory	52.2 MB
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	16 GB
Display diagonal	3 \
Display resolution	960 x 480 pixels
Display resolution (numeric)	460800 pixels
USB version	2.0
Product color	White
Scene modes	-
White balance	Auto, Daylight, Manual, Shade
Camera playback	Movie
Self-timer delay	2, 10 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3
Battery type	NP-130
Battery life (CIPA standard)	500 shots
Cables included	USB

Weight and Dimensions

Depth	28.6 mm
Width	104.8 mm
Height	59.1 mm
Weight	165 g
Weight (including battery)	205 g
